ONSEMI HCPL2631V High-speed optocoupler
The HCPL2631V is a 2-channel, 8-pin optocoupler featuring a high-speed 850nm AlGaAs LED coupled to a logic gate detector with a strobable, open-collector output. Designed for applications such as ground loop isolation, line reception, data transmission, and pulse transformer replacement, it provides excellent common-mode noise rejection with a typical immunity of 10kV/μs and a minimum of 5kV/μs. The device's parameters are guaranteed over a temperature range of -40°C to +85°C, supporting up to 5mA input signals for a minimum of 13mA output sink current, with a fan-out capability of 8. Its wired-OR, open-collector output design makes it suitable for various digital communication and signal processing applications.
ONSEMI HCPL2631V High-speed optocoupler Specifications:
- Type: 2-channel optocoupler
- Number of Pins: 8
- LED Wavelength: 850 nm
- Input Current: Up to 5mA support
- Output Sink Current: Minimum 13mA
- Fan-out Capability: 8
- Output Type: Open-collector, wired-OR
- Common Mode Immunity: Typical 10kV/μs, Min 5kV/μs
- Temperature Range: -40°C to +85°C
- Input Voltage: Not to exceed 5.5 V
- Isolation Voltage: 2500 V (withstand insulation test)
- Capacitance Input to Output: 0.6 pF
- Storage Temperature: -55°C to +125°C
- Supply Voltage: 45 V to 515 V
- Output Voltage: Up to 7 V
- Propagation Delay: 20-75 ns
- Rise & Fall Time: 12-50 ns
- Lead/Package: 8-pin DIP and surface-mount options
Buy the Fairchild HCPL2631V – Reliable Optocoupler for Industrial Applications
Purchase the Fairchild HCPL2631V online now to secure a high-performance, dual-channel optocoupler designed for industrial applications such as ground loop isolation, data communication, and power supply switching. Featuring a high-speed 850nm AlGaAs LED and open-collector logic gate output, it provides excellent common-mode noise immunity, supports up to 5mA input signals, and guarantees parameters over a wide temperature range. Buy now for fast delivery and ensure reliable, noise-free signal isolation in your projects.
Order your Fairchild HCPL2631V high-speed dual-channel optocoupler today and enhance the reliability of your industrial signal isolation and data transmission projects.
Frequently Asked Questions
Where can I buy ONSEMI HCPL2631V?
You can click on the BUY or RFQ button to purchase HCPL2631V from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part HCPL2631V?
You can download the HCPL2631V datasheet or visit the ONSEMI website for support.
Who is the manufacturer of HCPL2631V?
ONSEMI
