ONSEMI MC74LCX541DTG octal buffer
The MC74LCX541 is a high-performance, high-speed octal buffer with flow-through architecture, operating from 2.3 to 3.6 V supply. It features 5 V-tolerant inputs and outputs, supports live insertion, and provides TTL-compatible inputs and outputs with a high drive capability of 24 mA. The device includes an Output Enable pin for high impedance states, making it suitable for memory address driving and bus transceiver applications. Its low static power consumption, robust latching performance exceeding 500 mA, and certification for automotive and industrial standards ensure reliability in complex electronic systems.
ONSEMI MC74LCX541DTG octal buffer Specifications:
- Operating Voltage: 2.0 to 3.6 V, Data Retention 15 V
- Input Voltage: 0 to 5.5 V, Output Voltage: 0 to 5.5 V
- Output Drive Current: 24 mA, Power Dissipation Capacitance: 25 pF
- Maximum Ratings: Vcc -0.5 to +7.0 V, Storage Temperature -65°C to +150°C
- Operating Temperature: -40°C to +85°C, Input Transition Rise/Fall Time: 0 to 10 ns/V
- Propagation Delay: 15 to 75 ns, Output Enable/Disable: 15 to 95 ns
- ESD Tolerance: >2000 V Human Body Model, RoHS Compliant, Halogen and BFR Free
Buy the ON Semiconductor Series LCX Octal Buffer: MC74LCX541DTG
Purchase the ON Semiconductor octal buffer MC74LCX541DTG online today to ensure your electronic systems benefit from high-speed performance, 5 V-tolerant inputs/outputs, and low power consumption. This device supports critical applications such as memory addressing and bus transceivers, providing robust drive capability up to 24 mA and high impedance states for efficient system control. With certified reliability, RoHS compliance, and automotive-grade options, buying this component online guarantees quality, quick delivery, and the convenience of integrating a trusted solution into your designs.
Order your ON Semiconductor Series LCX MC74LCX541DTG octal buffer today and enhance the reliability and performance of your electronic projects with premium quality components.
Frequently Asked Questions
Where can I buy ONSEMI MC74LCX541DTG?
You can click on the BUY or RFQ button to purchase MC74LCX541DTG from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part MC74LCX541DTG?
You can download the MC74LCX541DTG datasheet or visit the ONSEMI website for support.
Who is the manufacturer of MC74LCX541DTG?
ONSEMI
