ONSEMI MOC3082M Triac Driver Optocoupler
The MOC3082M is a 6-pin DIP zero-cross triac driver optocoupler capable of handling an 800 Volt peak voltage. It features a GaAs infrared emitting diode and a monolithic silicon detector, designed for easy logic control of AC loads such as motors, relays, and lighting. The device offers excellent static dv/dt performance, UL1577 certification, and complies with IEC standards. It is ideal for usage in solid-state relays, industrial controls, and power switching applications, providing reliable optical isolation and precise zero-cross detection for safe power management.
ONSEMI MOC3082M Triac Driver Optocoupler Specifications:
- Input-to-Output Test Voltage, Method A: 1360 Vpeak
- Input-to-Output Test Voltage, Method B: 1594 Vpeak
- Maximum Working Insulation Voltage: 850 Vpeak
- Isolation Resistance at 500 V: >10^9 Ω
- Isolation Capacitance: 0.2 pF
- Operating Temperature Range: -40°C to +85°C
- Storage Temperature: -40°C to +150°C
- Total Device Power Dissipation at 25°C: 250 mW
- Lead Soldering Temperature: 260°C for 10 seconds
- Input Forward Voltage: 1.3 to 1.5 V at 30 mA
- Peak Surge Current (non-repetitive): 1 A
- Junction Temperature Range: -40°C to +100°C
Buy the ON Semiconductor MOC3082M – Reliable AC Power Control for Industrial Applications
Purchase the ON Semiconductor MOC3082M optocoupler online now to ensure high reliability and safety in your AC power switching and industrial control projects. This device offers zero-cross detection, 800V peak voltage handling, and excellent dv/dt performance, making it perfect for solid-state relays, motor starters, and lighting controls. With UL1577 certification and IEC60747 compliance, it guarantees safe electrical isolation and consistent operation. Order today for fast delivery and seamless integration into your power management systems, boosting performance and safety.
Order your ON Semiconductor MOC3082M zero-cross optocoupler today and ensure safe, efficient control for industrial relays, lighting, and motor drives.
Frequently Asked Questions
Where can I buy ONSEMI MOC3082M?
You can click on the BUY or RFQ button to purchase MOC3082M from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part MOC3082M?
You can download the MOC3082M datasheet or visit the ONSEMI website for support.
Who is the manufacturer of MOC3082M?
ONSEMI
