Ohmite FC4L16R020FER Current Sense Resistor
The FC4L series features four-terminal current sense resistors with metal foil construction, designed for stable resistance with low temperature coefficients. These high-heat-resistant components are suitable for automatic insertion, with sizes supporting 0.25W to 5W power ratings. They employ Ni-Cu-Mn resistive elements, offering precise current measurement and management. Different series cover resistance ranges from 10mΩ to 50mΩ, with features such as high overload capability, moisture resistance, and solderability, making them ideal for precision current sensing in electronic circuits.
Ohmite FC4L16R020FER Current Sense Resistor Specifications:
- Power Ratings: 0.25W, 1W, 2W, 5W
- Resistance Range: 10mΩ to 50mΩ
- Tolerance: ±2%, ±5%
- Temperature Coefficient of Resistance (TCR): +50 to +100 ppm/°C
- Operating Temperature Range: -55°C to +155°C
- Maximum Temperature for Rated Power: 70°C
- Soldering Temperature: 245°C for 3 seconds, compatible with reflow soldering
- Humidity Resistance: 90–95% RH at 60°C for 1000 hours
- Overload Voltage: Rated voltage x 1.5 (FC4L16 only)
- In-rush Current Capability: up to 100A depending on series
- Physical Size: Ranges supporting 0.063x1.6mm to 0.433x11.0mm with specific packaging
Buy the Ohmite Series FC4L Current Sense Resistor: FC4L16R020FER
Discover the reliability of the Ohmite Series FC4L current sense resistor, featuring metal foil construction for stability and precision. Designed for automatic insertion, these resistors support power ratings from 0.25W to 5W, with resistance values as low as 10mΩ. Built to withstand high overloads, moisture, and reflow soldering, they provide excellent temperature stability across a wide operating temperature range from -55°C to +155°C. Ideal for use in power supplies, motor control, and instrumentation, ensuring accurate current measurement in demanding environments.
Order your Ohmite Series FC4L16R020FER high-precision current sense resistor today and ensure reliable, accurate current measurement for your electronic projects.
Frequently Asked Questions
Where can I buy Ohmite FC4L16R020FER?
You can click on the BUY or RFQ button to purchase FC4L16R020FER from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part FC4L16R020FER?
You can download the FC4L16R020FER datasheet or visit the Ohmite website for support.
Who is the manufacturer of FC4L16R020FER?
Ohmite
