Ohmite FC4TR010FER Low Resistance Chip
The FC4T chip features four terminals in a Kelvin configuration, enabling precise current measurement by eliminating terminal resistance effects. Utilizing Ohmite's advanced Metal Foil technology, it maintains an excellent Temperature Coefficient of Resistance (TCR) down to 50ppm, even at very low resistance levels. With a power rating of 0.5W and resistance ranges from 0.005Ω to 0.100Ω, this chip is suitable for high-accuracy applications in various electronic and industrial systems. Its construction includes epoxy coating, copper-nickel-sn terminals, and an alumina substrate, ensuring durability and reliable performance across temperatures from -55°C to +155°C.
Ohmite FC4TR010FER Low Resistance Chip Specifications:
- Power Rating: 0.5W @70°C
- Resistance Range: 0.005Ω to 0.100Ω
- Resistance Tolerance: 0.5% and 1%
- Temperature Coefficient of Resistance: 50ppm
- Operating Temp Range: -55°C to +155°C
- Construction: Epoxy resin coating, Cu/Ni/Sn terminals, alumina substrate
- Max. Current: 27 to 55mA based on resistance
- Terminal Resistance: Less than 5mΩ
- Flammability: UL 94V-0
- Material: Metal foil chip with epoxy coating
- Size: 1206 package
- Peak Power: 0.5 watt
- Tolerance: 0.5% and 1% options
- Certification: RoHS compliant
- Resistance Stability: Maintains low TCR for accurate measurements
- Sensing accuracy: High due to Kelvin configuration
- Environmental Resistance: Excellent across -55°C to +155°C
- Resistance to overload and thermal shock validated by IEC standards
- Reliable solderability with >95% coverage in reflow conditions
Buy the Ohmite FC4T – Reliable Metal Foil Low Value Chip for Industrial Applications
Order the Ohmite FC4T low resistance chip online today and enhance your electronic measurement systems with its highly accurate Metal Foil technology. Featuring four Kelvin terminals, a wide resistance range, and robust construction, this component provides exceptional precision and stability across extreme temperatures. Perfect for industrial, aerospace, and advanced electronics applications, it ensures reliable performance with low TCR and excellent durability. Purchase now to secure fast delivery and technical support for your critical projects.
Buy Ohmite FC4T now and experience unmatched reliability and performance with high precision resistance measurement capabilities.
Frequently Asked Questions
Where can I buy Ohmite FC4TR010FER?
You can click on the BUY or RFQ button to purchase FC4TR010FER from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part FC4TR010FER?
You can download the FC4TR010FER datasheet or visit the Ohmite website for support.
Who is the manufacturer of FC4TR010FER?
Ohmite
