Ohmite HS102K2J Aluminium Housed Resistor
The HS Aluminium Housed Resistors are high-performance, direct heatsink-mounted components designed for high pulse capability and maximum thermal efficiency. Manufactured in compliance with MIL 18546 and IEC 115 standards, these resistors offer a wide resistance range from RO5 to 100K and various tolerances, including +5% and +10%. They feature low inductance, high insulation resistance, and linear derating at elevated temperatures. Suitable for power dissipation, heat transfer, and high ambient temperature conditions, these resistors are ideal for demanding industrial applications.
Ohmite HS102K2J Aluminium Housed Resistor Specifications:
- Power rating: From 4W to 300W depending on size
- Resistance range: R005 to 100K ohms
- Tolerance: +5% (J), +10% (K), with options for +1% (F), +2% (G), +3% (H)
- Temperature coefficients: <1K 100ppm, >1K 25ppm
- Insulation resistance: 10,000 MΩ minimum (dry)
- Surface temperature limit: 200°C maximum
- Physically available in sizes HS10 to HS300 with specific dimensions
- RoHS compliant
- Low inductance options available (NHS series)
- Operate with heat sinks, heat transfer enhanced by compound application
Buy the Buy Arcol Aluminium Housed Resistors Part Number HS102K2J Online
Purchase the Arcol HS102K2J aluminium housed resistor online today and enjoy high pulse capability, excellent thermal management, and reliable resistance performance. Perfect for industrial power circuits, these resistors feature direct heatsink mounting for maximum heat transfer and temperature stability. With resistance values from RO5 to 100K, various tolerances, and low inductance options, this high-quality resistor ensures durability and efficiency under demanding conditions. Buy now for seamless integration into your electronic or manufacturing systems.
Buy Arcol HS102K2J aluminium housed resistor now and experience reliable high pulse performance with efficient heatsink mounting.
Frequently Asked Questions
Where can I buy Ohmite HS102K2J?
You can click on the BUY or RFQ button to purchase HS102K2J from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part HS102K2J?
You can download the HS102K2J datasheet or visit the Ohmite website for support.
Who is the manufacturer of HS102K2J?
Ohmite
