Ohmite HS1075RJ High Power Aluminium Resistor
HS Aluminium Housed Resistors are designed for high power applications with direct heatsink mounting, optimal thermal performance, and compliance with MIL 18546 and IEC 115 standards. These reliable resistors are wound for high pulse capability, offering a wide ohmic value range from R005 to 100K. Featuring tolerance options from +1% to +10% and low inductance variants, they are suitable for demanding environments. The resistors' construction ensures thermal efficiency, with heat dissipation optimized via heat sink compounds, and they operate within a maximum surface temperature of 200°C, making them ideal for industrial power circuit needs.
Ohmite HS1075RJ High Power Aluminium Resistor Specifications:
- Power Dissipation: Up to 300 W with derating at high temperatures
- Ohmic Range: R005 to 100K depending on wattage size
- Tolerance Options: +1% (F), +2% (G), +3% (H), +5% (J), +10% (K)
- Insulation Resistance: Minimum 10,000 MO in dry conditions
- Temperature Coefficient: Typical < 100ppm/K for TCR < 1K, < 25ppm/K for TCR > 1K
- Maximum Surface Temperature: 200°C
- Voltage Rating: Divide maximum working voltage by 1.414 for NHS variants
- Dimensions: Size-specific dimensions ranging from 16.5 mm to 72.5 mm in width
- Heat Dissipation: Uses heat sink compound for efficient thermal transfer
- Surface Temperature Rise: Related to power dissipation; requires proper heatsinking
- Construction: Aluminium housing mounted with proprietary heat sink compound
- Compliance: RoHS compliant, suitable for high pulse and high current applications
Buy the Buy Arcol High Power Aluminium Housed Resistors Part Number HS1075RJ Online
Order the Arcol HS1075RJ aluminium housed resistor today for exceptional power handling, thermal performance, and reliable high pulse capabilities. Designed for direct heatsink mounting with thermal compound, these resistors deliver optimal efficiency in industrial power circuits. Available in multiple tolerance options, including +1% and +10%, they feature low inductance versions suitable for demanding environments. With robust construction and compliance to international standards, purchasing online ensures fast delivery, competitive pricing, and expert support for your engineering needs.
Get Arcol HS1075RJ today—built for high power performance, thermal efficiency, and long-lasting industrial reliability.
Frequently Asked Questions
Where can I buy Ohmite HS1075RJ?
You can click on the BUY or RFQ button to purchase HS1075RJ from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part HS1075RJ?
You can download the HS1075RJ datasheet or visit the Ohmite website for support.
Who is the manufacturer of HS1075RJ?
Ohmite
