Ohmite HS10R33J Aluminium Housed Resistor
The HS series aluminium housed resistors are engineered for high-power applications with direct heatsink mounting for optimal thermal performance. Designed to meet MIL 18546 and IEC 115 standards, these resistors offer high pulse capability, customizable ohmic values from R005 to 100K, and RoHS compliance. They feature various tolerances, temperature coefficients, and low inductance options for reliable operation in demanding environments. Suitable for industrial and power electronics where high heat dissipation, compact size, and robustness are essential, these resistors are ideal for high-temperature conditions up to 200°C with effective heat sinking and thermal management.
Ohmite HS10R33J Aluminium Housed Resistor Specifications:
- Power ratings: 10W to 300W depending on size and heatsink used
- Ohmic values: R005 to 100K
- Tolerance: +5% (J), +10% (K), also available +1% (F), +2% (G), +3% (H)
- Temperature Coefficient: <1K 100ppm, >1K 25ppm
- Insulation Resistance: Minimum 10,000 MΩ (dry)
- Maximum Surface Temperature: 200°C, with heat sink compound recommended
- Size varies from small compact units to larger high wattage models
- Design: Direct heatsink mounting, RoHS compliant
- Construction: Aluminium housing for effective heat dissipation and durability
- Application: Power electronics, industrial equipment, high pulse capability systems
Buy the Buy Arcol Aluminium Housed Resistors Part Number HS10R33J Online
Enhance your power electronics with the Arcol HS series aluminium housed resistor. Designed for high pulse capability and excellent thermal management, these resistors are ideal for industrial and demanding environments. Easy to mount directly onto heatsinks, they ensure maximum heat transfer and reliable operation up to 200°C. Solutions include various ohmic values, tolerances, and sizes to meet your specific needs. Order online today for fast delivery and assured quality, optimizing your system’s performance efficiently.
Buy Arcol HS10R33J aluminium housed resistor now and experience robust high-power performance and reliable thermal dissipation for demanding applications.
Frequently Asked Questions
Where can I buy Ohmite HS10R33J?
You can click on the BUY or RFQ button to purchase HS10R33J from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part HS10R33J?
You can download the HS10R33J datasheet or visit the Ohmite website for support.
Who is the manufacturer of HS10R33J?
Ohmite
