Ohmite HS25R22J High Power Resistor
The HS25 aluminium housed resistor is designed for high power applications with direct heatsink mounting using thermal compound. It features ultra-high pulse capability, various ohmic values from R005 to 100K, and tolerance options including +1%, +2%, +3%, +5%, and +10%. Suitable for rugged industrial environments, this resistor dissipates power linearly to a maximum of 200°C and is RoHS compliant. Its compact design ensures high performance with low inductance, making it ideal for precise power control and high pulse applications.
Ohmite HS25R22J High Power Resistor Specifications:
- Power Dissipation: Ranges from 4W to 300W depending on model
- Resistance Values: From R005 to 100K ohms
- Tolerance: +1%, +2%, +3%, +5%, +10%
- Temperature Coefficient: Typically < 1K 100ppm, > 1K 25ppm
- Insulation Resistance: 10,000 MΩ minimum (Dry)
- Surface Temperature Rise: Related to power dissipation, max 200°C
- Voltage Proof AC: 415-995 V depending on model
- Dimensions: Varied sizes with detailed max dimensions in mm
- Mounting: Aluminium heatsink, with optional low inductance (NHS) series
- RoHS Compliant: Yes
- Construction: Wound for high pulse capability, direct heatsink mountable
- Material: Aluminium housing with thermal compound interface
- Peak RMS Voltage: Ranges from 1400 V to 7070 V depending on model
- Limiting Element Resistance: Based on wattage and size
Buy the Buy Arcol HS25 R22J Part Number HS25R22J Online
Purchase the Arcol HS25 aluminium housed resistor online today to leverage its high power dissipation, thermal efficiency, and precision resistance values. Designed for direct heatsink mounting with thermal compound, it offers reliable performance for industrial power control and high pulse applications. With ohmic values from R005 to 100K and tolerances up to ±1%, this RoHS-compliant resistor is ideal for rugged environments. Its compact size and low inductance ensure optimal heat management and electrical performance, making it the perfect choice for engineers seeking quality and durability in power resistors.
Order your Arcol SeriesHS25 R22J aluminium housed resistor today and ensure reliable high power performance in your industrial projects.
Frequently Asked Questions
Where can I buy Ohmite HS25R22J?
You can click on the BUY or RFQ button to purchase HS25R22J from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part HS25R22J?
You can download the HS25R22J datasheet or visit the Ohmite website for support.
Who is the manufacturer of HS25R22J?
Ohmite
