Ohmite LVT12R0200FER Low Value Current Sense Resistor
The Ohmite LVT series comprises metal alloy strip resistors designed for low value current sensing with high stability. Features include TCR ratings down to 50ppm, resistance from 2m to 20m ohms, and tight tolerances of 1%. Suitable for various applications, these resistors operate within -55°C to 155°C, with power ratings up to 1.0W depending on size. They are encapsulated with epoxy resin, have tin-plated terminations, and meet UL-94-VO flame retardant standards, ensuring reliability in demanding environments.
Ohmite LVT12R0200FER Low Value Current Sense Resistor Specifications:
- Resistance Range: 0.002-0.020 ohms depending on size and TCR
- Power Ratings: 0.33W (0402, 0603, 0805), 1.0W (1206)
- Operating Temperature Range: -55°C to 155°C
- Rated Ambient Temperature: +70°C
- Resistance Tolerance: 1%, 2%, 3%
- Temperature Coefficient: 50, 75, 100, 150 ppm/°C
- Coating Material: epoxy resin
- Terminals: 100% matte tin
- Storage Conditions: 2 years airtight, +10°C to +40°C, humidity <75%
- Construction: Cu-alloy resistor with flame-retardant epoxy, meets UL-94-VO
- Solderability: Resistance to solder heat at 275°C for 45 sec
- Mechanical Shock: 100G, 11 ms, 5x
- Reflow Soldering: Max temp 260°C for 10 sec, preheat up to 130°C
Buy the Ohmite R0020FER – Reliable Low Value Current Sense for Industrial Applications
Discover the Ohmite R0020FER low value current sense resistor, engineered for precision in industrial circuits. With resistance from 2m to 20m ohms and TCR ratings as low as 50ppm, it ensures stability under extreme temperature conditions. Its compact size and high power ratings make it ideal for demanding electronic applications. Benefit from reliable performance, tight tolerances, and UL-94-VO flame resistance. Purchase online today to enhance your electronic designs with high-quality resistors that deliver durability, accuracy, and consistent performance in industrial environments.
Get Ohmite R0020FER today—built for precision and long-lasting durability in current sensing applications.
Frequently Asked Questions
Where can I buy Ohmite LVT12R0200FER?
You can click on the BUY or RFQ button to purchase LVT12R0200FER from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part LVT12R0200FER?
You can download the LVT12R0200FER datasheet or visit the Ohmite website for support.
Who is the manufacturer of LVT12R0200FER?
Ohmite
