Ohmite TAP650J1K0E High-Power Ceramic Resistor
The TAP650J1K0E is a high-power, low profile resistor designed for use in variable speed drives, power supplies, control devices, robotics, and motor control. It features high-purity ceramic metallized construction with a film on the bottom for optimal heat transfer and discharge. Encased in a special resin-filled epoxy casing, it offers high insulation resistance (CTI 600), high dielectric strength, and partial discharge capability. Able to withstand 650W at 85°C, it has a resistance range from 0.25 to 1MΩ, with low inductance and capacitance, ensuring stability under high wattage and pulse loads. Its features include high temperature resistance, voltage ratings up to 12kV, and robust mechanical design for durability in demanding electrical environments.
Ohmite TAP650J1K0E High-Power Ceramic Resistor Specifications:
- Power Rating: 650W at 85°C bottom case temperature
- Resistance Range: 0.25Ω to 1MΩ (others upon request)
- Maximum Voltage: 5,000VDC, up to 12kV with special request
- Peak Current: Up to 1,500A depending on pulse length and frequency
- Insulation Resistance: 10 GΩ at 500V
- Capacitance: 110pF (body), 40pF (parallel)
- Operating Temperature: -55°C to +150°C
- Thermal Resistor: 8.55W/°K (0.117°C/W)
- Dimensions: Approximate size 2.606
- Dimensions: Approximate size 66.2-66.7mm x 25.5-26.5mm x 5.3-5.8mm
- Material: Ceramic metallized with resin-filled epoxy casing
- Resistance Tolerance: ±10% (others upon request)
- Peak Current: Up to 1500A depending on pulse and frequency
- Voltage Strength: 6kVrms standard, up to 12kVrms upon request
- Partial Discharge Capability: 4KVrms, <10 pC, up to 7kV upon special request
- Temperature Coefficient: +150 ppm/°C
- Insulation Resistance: Min. 10 GΩ at 500V
- Resistance Values: Ranges from 0.25Ω to 1 MΩ, specific resistances available upon request
- Mounting Torque: 1.8 Nm with M4 screws
- Housing Material: UL94-VO compliant epoxy resin
- Operating Temperature Range: -55°C to +150°C
- Derating Resistance: 8.55 W/°K with thermal transfer compound
