Ohmite TAP650J500E High Power Resistor
The TAPG50 Series resistor delivers high power capacity of 650W at 85°C, designed with a low profile, high insulation resistance, and excellent heat transfer features. It features a ceramic metalized construction with film on the bottom for efficient heat dissipation, a special resin-filled epoxy casing for durability, and low inductance and capacitance for stable pulse load performance. Suitable for various power control applications, including variable speed drives, robotics, and motor control, with high dielectric strength and partial discharge capability, making it ideal for demanding industrial environments.
Ohmite TAP650J500E High Power Resistor Specifications:
- Power: 650W at 85°C bottom case temperature
- Resistance Range: 0.25 to 1 MΩ (others upon request)
- Voltage: Max 5,000VDC, up to 12kV rms upon special request
- Peak Current: Up to 1,500A depending on pulse length and frequency
- Insulation Resistance: 10 GΩ min at 500V
- Temperature Coefficient: +150 ppm/°C
- Operating Temperature: -55°C to +150°C
- Maximum working voltage: 5,000VDC
- Dielectric Strength: 6kVrms (up to 12kVrms upon request)
- Partial Discharge: 4kVrms, <10 pC, up to 7kV upon special request
- Inductance: 80 nH (typical)
- Dimensions: Approximate size 2.606
Buy the Ohmite Series TAPG High-Power Resistor: TAP650J500E
Order the high power 650W resistor series online today and experience superior heat transfer, stable pulse handling, and high insulation resistance ideal for industrial power and control systems. Crafted with ceramic metallization and epoxy casing, this resistor ensures durability, safety, and reliable operation under demanding conditions. Its compact low-profile design allows for efficient integration into variable speed drives, robotics, and motor control units. Purchase now for a robust solution that guarantees precision performance and long-lasting efficiency in your critical power applications.
Get Ohmite TAP650J500E today—built for high power, durability, and reliable performance in demanding electrical applications.
Frequently Asked Questions
Where can I buy Ohmite TAP650J500E?
You can click on the BUY or RFQ button to purchase TAP650J500E from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part TAP650J500E?
You can download the TAP650J500E datasheet or visit the Ohmite website for support.
Who is the manufacturer of TAP650J500E?
Ohmite
