OMRON ELECTRONIC COMPONENTS SS5F Subminiature Basic Switch
The Omron SS series subminiature basic switches are highly reliable and designed for industrial automation, security, and power management applications. They feature a switching capacity of up to 10.1A at 250VAC, 5A at 125VAC, and 0.1A at 30VDC, offering versatile use in various circuits. Equipped with multiple actuator options such as pin, hinge, long hinge, simulated roller, and roller lever, they accommodate different operational needs. Available in solder, quick connect, and PCB terminals, with operating forces from 0.06N to 1.47N, and configurations including SPDT, SPST-NC, and SPST-NO, these switches deliver high durability, with split springs supporting over 30 million operations.
OMRON ELECTRONIC COMPONENTS SS5F Subminiature Basic Switch Specifications:
- Switching Capacity: 10.1A at 250VAC, 5A at 125VAC, 0.1A at 30VDC
- Actuator Options: Pin plunger, hinge, long hinge, simulated roller, roller lever
- Terminal Types: Solder, quick connect, PCB terminals
- Operating Force Range: 0.06N to 1.47N
- Contact Configurations: SPDT, SPST-NC, SPST-NO
- Durability: Over 30 million operations with split springs
- Temperature Resistance: Standard (85°C) and Heat-resistant (120°C) models available
- Compliance: RoHS
- Mounting Holes: 2.2 mm diameter or M2.3 screw holes
- Dimensions: Referenced in technical diagrams
- Material: Polyacetal resin, stainless-steel lever, silver/gold alloy contacts
Buy the Omron SS Series Reliable Micro Switches for Industrial Applications
Purchase Omron SS series micro switches online today for superior reliability and versatility. Suitable for industrial automation, power control, and security systems, these switches feature multiple actuator and terminal options, high durability, and a maximum current capacity of 10.1A at 250VAC. With operating forces from 0.06N to 1.47N and over 30 million cycles, they ensure long-lasting performance. Easy to install on flat surfaces with standard mounting holes, they are ideal for demanding industrial and security applications worldwide.
Get Omron SS series switches today—built for precision, high load capacity, and long-lasting durability in industrial environments.
Frequently Asked Questions
Where can I buy OMRON ELECTRONIC COMPONENTS SS5F?
You can click on the BUY or RFQ button to purchase SS5F from an authorized OMRON ELECTRONIC COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part SS5F?
You can download the SS5F datasheet or visit the OMRON ELECTRONIC COMPONENTS website for support.
Who is the manufacturer of SS5F?
OMRON ELECTRONIC COMPONENTS
