OMRON ELECTRONIC COMPONENTS G6A234PSTUSDC5 Low Signal Relay
The G6A-234P-ST-US-DC5 is a non-latching, low-signal relay with a DC coil, part of the G6A series. It features DPDT gold-plated contacts, a compact 12.7 mm design ideal for PCB mounting, and complies with FCC surge voltage standards. Its design reduces size, magnetic interference, and contact bounce, allowing high-sensitivity operation and side-by-side installation. Suitable for industrial automation, telecommunication, and control systems, it operates from -40°C to 70°C, ensuring reliable performance in harsh environments for low-voltage switching applications.
OMRON ELECTRONIC COMPONENTS G6A234PSTUSDC5 Low Signal Relay Specifications:
- Contact Material: Au-Clad (Gold-plated) contacts
- Contact Form: DPDT
- Coil Voltage: DC 5V
- Coil Resistance: Not specified externally, rated for 5V DC coil
- Contact Resistance: 50 mΩ max.
- Switching Voltage: Max. 250 VAC, 220 VDC
- Switching Current: Max. 2 A
- Operating Temperature Range: -40°C to 70°C
- Dimensions: Width 12.7 mm (0.5 inch), mounting depth compatible with PCB
- Surge withstand voltage: 1,500 V complying with FCC Part 68
- Mechanical Life: 100 million operations
- Electrical Life: 500,000 operations
Buy the Omron Series G6A Low Signal Relay: G6A234PSTUSDC5
Purchase the Omron G6A234PSTUSDC5 relay online today to enhance your industrial automation or telecommunications projects. Featuring gold-plated contacts for high reliability, a compact 12.7 mm footprint for easy PCB integration, and a wide operating temperature range from -40°C to 70°C, this relay ensures dependable performance and long life. Suitable for high-speed switching with minimal bounce, it complies with FCC surge standards. Order now for fast delivery and superior control solutions for your equipment.
Get Omron G6A234PSTUSDC5 today—built for precision and long-lasting durability in industrial control systems.
