OMRON ELECTRONIC COMPONENTS XF2M33151A Rotary Connector
The XF2M33151A is a high-reliability rotary backlock connector designed for fine-pitch FPC/FFC applications. Its dual-sided contact reduces parts count while offering excellent electrical performance. Suitable for 0.3 mm thick flexible PCBs, it features gold-plated contacts, UL94 V-0 rated LCP housing, and a rated current of 0.5 A at 50 V for AC/DC. The connector is RoHS compliant, halogen-free, has a dielectric strength of 250 V AC, contact resistance of max 50 mΩ, and withstands 20 insertion cycles with stable insulation resistance of minimum 700 MΩ. Dimensions vary with model for versatile design integration.
OMRON ELECTRONIC COMPONENTS XF2M33151A Rotary Connector Specifications:
- Rated current: 0.5 A at 50 V AC/DC
- Housing Material: LCP resin (UL94 V-0)
- Contact Material: Copper alloy with nickel substrate and gold plating (0.15 μm)
- Insulation Resistance: ≥700 MΩ at 250 V DC
- Dielectric Strength: 250 V AC for 1 min
- Insertion Durability: 20 cycles
- Operating Temperature: 30 to 85°C with no icing or condensation
- Dimensions: Vary with model, e.g., length 34.0 mm for larger variants
- RoHS and Halogen-Free Compliance: Yes, with limits of 900 ppm for Br and Cl
- Rated voltage: 50 V AC/DC
Buy the Omron XF2M33151A – Reliable Rotary Backlock Connector for Industrial Applications
Discover the reliable and versatile Rotary Connector designed for high-density FPC/FFC applications. Featuring dual-sided contacts with gold plating, halogen-free construction, and compliance with RoHS standards, this connector ensures durable electrical connections in compact equipment. Its robust design supports 20 insertion cycles, with a rated current of 0.5 A at 50 V AC/DC and an insulation resistance of at least 700 MΩ. Ideal for industrial automation, consumer electronics, and communication devices, it offers excellent performance in challenging environments.
Buy Omron XF2M33151A now and experience unmatched reliability and high-performance electrical connections for your industrial projects.
Frequently Asked Questions
Where can I buy OMRON ELECTRONIC COMPONENTS XF2M33151A?
You can click on the BUY or RFQ button to purchase XF2M33151A from an authorized OMRON ELECTRONIC COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part XF2M33151A?
You can download the XF2M33151A datasheet or visit the OMRON ELECTRONIC COMPONENTS website for support.
Who is the manufacturer of XF2M33151A?
OMRON ELECTRONIC COMPONENTS
