OMRON G6S2FYDC12 Signal Relay
This signal relay features a 12 VDC coil voltage and a 2C DPDT contact configuration, capable of handling up to 2 amps. It is designed for surface mounting and operates as a single side stable relay. The relay is certified to meet safety standards including UL, CSA, and EN60950/EN41003 with a high dielectric withstand voltage of 2,000 VAC between coil and contacts. It offers low power consumption of 140 mW, and is available in through-hole and surface mount types with tape and reel packaging options. Suitable for industrial automation and control applications, it provides reliable switching with high surge withstand capacity and complies with RoHS standards.
OMRON G6S2FYDC12 Signal Relay Specifications:
- Contact Resistance: 75 mΩ max
- Operate Time: 4 ms max
- Release Time: 4 ms max
- Bounce Time: Approx. 0.5 ms
- Max Switching Capacity: 62.5 VA, 60 W
- Max Operating Current: 2A
- Rated Coil Voltage: 12 VDC
- Coil Resistance: 1,440 Ω
- Power Consumption: Approx. 140 mW
- Dielectric Strength: 2,000 VAC between coil and contacts
- Insulation Resistance: 1,000 MΩ at 500 VDC
- Temperature Range: -40°C to +85°C
- Weight: Approx. 2 grams
- Certification: UL Recognized, CSA Certified, EN60950/EN41003
- Terminal Type: Surface mount, through-hole, tape and reel packaging
- Operating Life: Mechanical 100 million operations, Electrical 100,000 operations
Buy the Omron Series G6S Signal Relay: G6S2FYDC12
Discover the advanced Omron G6S2FYDC12 surface mount signal relay, featuring 12 VDC coil voltage, 2A contact capacity, and high dielectric voltage. Perfect for industrial control, automation systems, and safety-critical applications, this relay offers low power consumption of 140 mW and meets safety standards including UL and CE. Equipped with comprehensive certifications and versatile packaging options, it ensures reliable switching, surge withstand capacity, and durability. Enhance your system's performance today by purchasing this robust relay online and enjoy seamless integration and exceptional operational stability.
Buy Omron G6S2FYDC12 surface mount relay now and experience unmatched reliability and performance in your automation and control projects.
Frequently Asked Questions
Where can I buy OMRON G6S2FYDC12?
You can click on the BUY or RFQ button to purchase G6S2FYDC12 from an authorized OMRON distributor.
How do I troubleshoot issues or seek technical support for part G6S2FYDC12?
You can download the G6S2FYDC12 datasheet or visit the OMRON website for support.
Who is the manufacturer of G6S2FYDC12?
OMRON
