OPTO 22 SSRHS Heatsink Solid-State Relay
The SSRHS is an integrated heatsink solid-state relay designed for reliable operation in various industrial applications. It features an internal heatsink that ensures efficient heat dissipation, reducing thermal resistance and enhancing overall durability. The relay has a nominal current rating of 30 amps and operates within a voltage range of 24-280V AC. With a built-in hardware for screw mounting and a DIN-rail clip, it allows easy installation. It provides 4,000 volts of optical isolation, operates at frequencies between 25 to 65 Hz, and boasts UL and CSA recognition for safety compliance.
OPTO 22 SSRHS Heatsink Solid-State Relay Specifications:
- Nominal AC Line Voltage: 240V, 480V, 575V
- Operating Voltage Range: 24-280V AC, 100-530V AC, 100-600V AC respectively
- Peak Repetitive Voltage Maximum: 600V, 1000V, 1200V
- Off-State Leakage: 5mA, 10mA, 12mA maximum
- Nominal Output Voltage Drop: 1.0 volts RMS
- Nominal Current Rating: 30A, 25A, 30A respectively
- Surge Peak Current (1 cycle): 610A at 60Hz and 50Hz
- Isolation Voltage (transient): 4KV
- Dissipation: 1.0 Watts per Amp
- Operating Temperature Range: -40°C to 100°C
- Control Signal Input Resistance: 730Ω, 1000Ω, 1000Ω
- Turn-on Time: 100μs, Turn-off Time: 750μs
- Thermal Resistance (junction to ambient): 22°C/W
Buy the Buy Opto 22 SSRHS Part Number SSRHS Online
Purchase the Opto 22 SSRHS heatsink relay online for reliable, efficient heat management in industrial applications. It features a 30A current rating, wide voltage compatibility, and UL/CSA recognition. Designed with an integrated heatsink and easy DIN-rail mounting, it ensures optimal thermal performance and simplified installation. Suitable for demanding environments, this relay's robust construction guarantees longevity and safety. Get yours today to enhance your automation projects with dependable, high-quality solid-state switching performance backed by Opto 22's trusted reliability and extensive testing protocols.
Order your Opto 22 SSRHS heatsink relay today and enjoy dependable heat dissipation for reliable industrial switching and control solutions.
Frequently Asked Questions
Where can I buy OPTO 22 SSRHS?
You can click on the BUY or RFQ button to purchase SSRHS from an authorized OPTO 22 distributor.
How do I troubleshoot issues or seek technical support for part SSRHS?
You can download the SSRHS datasheet or visit the OPTO 22 website for support.
Who is the manufacturer of SSRHS?
OPTO 22
