Panasonic 6SEPC1500M Conductive Polymer Capacitor
The Panasonic 6SEPC1500M is a high-performance conductive polymer aluminum electrolytic capacitor designed for a wide range of industrial applications. Its key features include super low ESR (5 mΩ max.) and a large capacitance (2700 μF max.), ensuring efficient power delivery and stability. The capacitor is RoHS compliant and halogen-free, meeting stringent environmental standards. It exhibits excellent endurance and capacitance change characteristics, making it suitable for demanding applications such as power supplies, DC-DC converters, and audio equipment. The 6SEPC1500M offers a reliable and compact solution for various electronic circuits.
Panasonic 6SEPC1500M Conductive Polymer Capacitor Specifications:
- Rated voltage range: 2.5 to 16 V
- Nominal cap.range: 100 to 2700 μF
- Capacitance tolerance: ±20 %
- Ripple current: 4180 mA rms
- ESR: 7 mΩ max.
- tan δ: 0.10
- Endurance: +105 ℃ 5000 h
- DC leakage current: Within the initial limit
- Damp heat: +60 ℃,90 % to 95 %,1000 h
Buy the 6SEPC1500M PANASONIC Conductive Polymer Capacitor | myMectronic
Purchase the Panasonic 6SEPC1500M securely and efficiently for your industrial needs.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic 6SEPC1500M?
You can click on the BUY or RFQ button to purchase 6SEPC1500M from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part 6SEPC1500M?
You can download the 6SEPC1500M datasheet or visit the Panasonic website for support.
Who is the manufacturer of 6SEPC1500M?
Panasonic
