Panasonic 80SXE47M Conductive Polymer Aluminum Capacitor
The Panasonic Conductive Polymer Aluminum Solid Capacitors are high-performance, radially leaded devices designed for applications requiring high voltage and temperature stability. These capacitors feature RoHS compliance and halogen-free construction, ensuring environmentally friendly design. They operate efficiently at temperatures from -55°C to +125°C and can handle voltages up to 100 VDC. Suitable for power electronics, motor drives, and industrial equipment, these capacitors offer low ESR, excellent endurance, and reliable performance in demanding environments, making them ideal for professional electronic and industrial applications.
Panasonic 80SXE47M Conductive Polymer Aluminum Capacitor Specifications:
- Series: SXE
- Size codes: E7, E12, F13, F8, FA3
- Rated voltage: 63 VDC to 100 VDC
- Capacitance range: 6.8 μF to 68 μF
- Temperature range: -55 °C to +125 °C
- Leakage current and dissipation factor: per attached characteristics list
- Endurance: 1000 h at +125 °C with rated voltage, capacitance within +20%
- Damp heat: 1000 h at +60 °C, 90-95 % RH, no applied voltage, capacitance within +20%
- Physical dimensions: specify in external datasheet, typical sizes from 8 mm to 13 mm diameter
- ESR: 340 mΩ to 1030 mΩ at 100 kHz
- Ripple current: 42 to 188 A depending on model, with frequency correction factors
- Polarity marked (-), long life and reliable performance
Buy the Panasonic Series SXE Conductive Polymer Aluminum Capacitors: 80SXE47M
Order the Panasonic Series SXE 80SXE47M aluminum solid capacitor online today to ensure high voltage stability, excellent endurance, and environmentally friendly design tailored for industrial electronics and power management solutions. With RoHS compliance and halogen-free construction, this capacitor guarantees reliable operation from -55°C to +125°C, handling voltages up to 100 VDC. Perfect for demanding applications requiring low ESR and long-lasting performance. Purchase now for efficient and dependable electronic component sourcing with fast delivery and excellent support.
Buy Panasonic Series SXE 80SXE47M now and experience unmatched reliability and performance in high-voltage, temperature-resistant aluminum capacitors.
Frequently Asked Questions
Where can I buy Panasonic 80SXE47M?
You can click on the BUY or RFQ button to purchase 80SXE47M from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part 80SXE47M?
You can download the 80SXE47M datasheet or visit the Panasonic website for support.
Who is the manufacturer of 80SXE47M?
Panasonic
