Panasonic CN14ARC1 Micro Photoelectric Sensor
The U-shaped Micro Photoelectric Sensor series offers compact design, IP64 waterproof rating, and easy mounting with M2 or M3 screws. Equipped with three protection circuits—reverse supply polarity, reverse output polarity, and output short-circuit—these sensors are ideal for industrial positioning, object detection, and limit sensing applications. They feature a sensing distance of 6 mm, an infrared LED emitter with a wavelength of 855 nm, and incorporate a large LED operation indicator for easy setup. Cable extension up to 100 meters is supported, ensuring flexibility for various system configurations. Resistant to vibrations and impacts, with a robust PBT enclosure, these sensors guarantee reliable operation in demanding environments.
Panasonic CN14ARC1 Micro Photoelectric Sensor Specifications:
- Sensing range: 6 mm (fixed)
- Minimum sensing object: 0.8 x 4.2 mm opaque object
- Hysteresis: 0.05 mm or less
- Repeatability: 0.01 mm or less
- Supply voltage: 4.5 V or more DC, 5-24 V DC recommended
- Current consumption: 15 mA or less
- Output: NPN or PNP open-collector transistor, max. 50 mA
- Output voltage: 30 V DC or less
- Residual voltage: 2 V or less at 50 mA
- Protection: IP64, reverse polarity, short-circuit, surge absorption
- Temperature range: -25°C to +55°C
- Cable length: 1 m or 3 m, extension up to 100 m with 0.3 mm² cable
- Material: Enclosure of PBT, display section of polycarbonate
- Weight: 10 g (net), 15 g (gross) for small models
- Vibration resistance: 10 to 2,000 Hz, 1.5 mm amplitude
- Shock resistance: Approx. 1500 G acceleration
- Infrared LED peak wavelength: 855 nm
Buy the Industrial Sensors Series Micro Photoelectric Sensor: CN14ARC1
Enhance your automation system with the CN14ARC1 micro photoelectric sensor, offering reliable 6mm sensing distance, IP64 waterproof rating, protection circuits, and extended cable options up to 100 meters. Its compact, easy-to-mount design with robust enclosure guarantees stable performance in demanding environments. Perfect for object detection, position sensing, and industrial automation tasks, this sensor ensures precise operation, quick setup with mounting compatibility, and long-term durability—making it an ideal choice for modern manufacturing and control solutions.
Buy CN14ARC1 micro photoelectric sensor now and ensure precise detection with superior durability and easy installation for industrial automation.
Frequently Asked Questions
Where can I buy Panasonic CN14ARC1?
You can click on the BUY or RFQ button to purchase CN14ARC1 from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part CN14ARC1?
You can download the CN14ARC1 datasheet or visit the Panasonic website for support.
Who is the manufacturer of CN14ARC1?
Panasonic
