Panasonic ECEA0JN101U Aluminum Electrolytic Capacitor
The Panasonic ECE-A0JN101U is a radial lead, bipolar aluminum electrolytic capacitor suitable for a wide range of applications requiring stable capacitance and reliable performance. Featuring an endurance of 85°C for 2000 hours, this capacitor is designed to withstand demanding operating conditions. It is RoHS compliant, demonstrating a commitment to environmental responsibility. The capacitor's bipolar design provides flexibility in circuit design, and its radial lead configuration simplifies integration into various PCB layouts. Ideal for power supplies, filtering circuits, and other critical applications.
Panasonic ECEA0JN101U Aluminum Electrolytic Capacitor Specifications:
- Endurance: 85 °C 2000 h
- RoHS Compliant: Yes
- Category Temperature Range: -40 °C to +85 °C
- Rated W.V. Range: 6.3 V.DC to 50 V.DC
- Nominal Cap. Range: 2.2 μF to 6800 μF
- Capacitance Tolerance: ±20 % (120 Hz/+20 °C)
- DC Leakage Current: < 0.03 CV +3 (μA) After 5 minutes
- tan d: Please see the attached standard products list.
- Endurance Capacitance Change: ± 20 % of initial measured value
- Endurance tan d: < 150 % of initial specifi ed value
- Endurance DC Leakage Current: < initial specifi ed value
- Shelf Life: Meets endurance limits after storage at +85 °C
- Frequency Correction Factor (50/60 Hz): 0.70
- Frequency Correction Factor (120 Hz): 1.30
- Frequency Correction Factor (1 k Hz): 1.70
- Sleeve: 08 to 18 mm
- Pressure Relief: 06.3 mm
- Lead Dia.: 0.5 to 0.8 mm
- Lead Space: 2.0 to 7.5 mm
