Panasonic ECWFD2J183KB Polypropylene Film Capacitor
The metallized polypropylene film capacitor series features non-inductive construction using metallized polypropylene film with a flame-retardant epoxy resin coating. Designed for high-frequency applications, these capacitors offer excellent frequency characteristics, low loss, and low hum noise. They are RoHS compliant and suitable for active filter circuits and high-frequency circuit applications, providing reliable performance and safety. The ECWFD series adheres to strict safety, environmental, and quality standards, making it ideal for various industrial and electronic applications requiring stable, low-loss, high-frequency filtering with flame retardant features.
Panasonic ECWFD2J183KB Polypropylene Film Capacitor Specifications:
- Capacitance range: 0.01 pF to 4.7 μF
- Rated voltage: 450 V DC / 630 V DC
- Temperature range: -40°C to +110°C (450V), -40°C to +105°C (630V)
- Capacitance tolerance: ±5% (J), ±10% (K)
- Dissipation factor (tan δ): ≤0.1% at 20°C, 1 kHz
- Withstand voltage: 1.5 × rated voltage for 60 seconds
- Insulation resistance: ≥30,000 MΩ (C ≤ 0.33 μF), ≥10,000 MΩ (C > 0.33 μF)
- RoHS compliant
- Lead form: Straight, crimped, cut, taping options available
- Product dimensions vary with capacitance and voltage, with standardized lead spacing and packaging options
- Applications include active filter circuits, high-frequency circuits, and environments requiring flame retardant components.
- Design and specifications are subject to change; verify current specs before use. Proper handling and mounting precautions are recommended for safety and performance.
Buy the Panasonic ECWFD – Reliable High-Frequency Capacitor for Industrial Applications
Enhance your electronic designs with Panasonic ECWFD series polypropylene film capacitors. Offering excellent frequency response, low dielectric loss, and flame retardant epoxy coatings, these capacitors ensure high performance and safety in industrial applications. Ideal for active filters and high-frequency circuits, they provide stable operation across a wide temperature range. Purchase online today to benefit from quick delivery, reliable quality, and technical support from Panasonic, ensuring your projects meet the highest standards of performance and safety.
Buy Panasonic ECWFD series film capacitors now and experience unmatched reliability, low loss, and flame-retardant safety for high-frequency industrial applications.
Frequently Asked Questions
Where can I buy Panasonic ECWFD2J183KB?
You can click on the BUY or RFQ button to purchase ECWFD2J183KB from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECWFD2J183KB?
You can download the ECWFD2J183KB datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECWFD2J183KB?
Panasonic
