Panasonic ECWFD2W474J4 Metallized Polypropylene Capacitor
The Panasonic ECW-FD2W474J4 is a metallized polypropylene film capacitor offering a robust and reliable solution for a wide range of electronic applications. Its non-inductive design, combined with a flame-retardant epoxy resin coating, ensures excellent performance and safety. This capacitor is particularly well-suited for active filter circuits and high-frequency, high-current applications where stability and low loss are critical. The capacitor's RoHS compliance further enhances its appeal for environmentally conscious designs. Available in various capacitance ranges and tolerances, the ECW-FD2W474J4 provides flexibility for diverse circuit requirements.
Panasonic ECWFD2W474J4 Metallized Polypropylene Capacitor Specifications:
- Category temp. range: －40℃to＋110℃
- Rated voltage: 450 VDC (Derating of rated voltage by 0.62%/˚C at more than 85˚C. Peak to peak voltage applied on the capacitor should be less than 240Vp-p, and zero to peak voltage should be less than 450V.)
- Capacitance range: 0.1 µF to 4.7 µF
- Capacitance tolerance: ±5 %(J), ±10 %(K)
- Withstand voltage: Between terminals:Rated voltage (VDC)×150 % 60 s
- Dissipation factor: tanδ≦0.1 % (20 ˚C,1 kHz)
- Insulation resistance: C≦0.33 µF:IR≧30,000MΩ; C＞0.33 µF:IR≧10,000MΩ・µF (20℃,100VDC,60 s)
Buy the ECW-FD2W474J4 PANASONIC Metallized Polypropylene Capacitor | myMectronic
Purchase the Panasonic ECW-FD2W474J4 capacitor securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic ECWFD2W474J4?
You can click on the BUY or RFQ button to purchase ECWFD2W474J4 from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECWFD2W474J4?
You can download the ECWFD2W474J4 datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECWFD2W474J4?
Panasonic
