Panasonic EEEHA1A101WP Aluminum Electrolytic Capacitor
The Panasonic HA series aluminum electrolytic surface mount capacitors are designed for high-reliability applications, offering long service life at 105°C with 1000 hours endurance. These vibration-proof and RoHS compliant components feature a wide capacitance range from 1UF to 1500UF, rated voltages from 6.3V to 100V, and are suitable for various electronic equipment including home appliances, computers, and optical devices. They are manufactured with precise dimensions, low ESR, and excellent temperature stability, making them ideal for demanding environments requiring reliable operation and stable performance.
Panasonic EEEHA1A101WP Aluminum Electrolytic Capacitor Specifications:
- Category temperature range: -40°C to +105°C
- Rated voltage range: 6.3 V to 100 V
- Capacitance range: 1 UF to 1500 UF
- Capacitance tolerance: ±20% (120 Hz / +20°C)
- Leakage current: |S 0.01 CV or 3 (μA) after 2 minutes
- Endurance: 105°C, 1000 hours
- Impedance ratio Z (-25°C)/Z (+20°C): 4.93 to 2 (varies by size)
- Maximum ripple current varies with size and temperature
- RoHS and AEC-Q200 compliant
- Dimensions and support terminals vary across sizes with specific layout for surface mounting
- Supports reflow and vapor phase soldering under specified conditions
- Designed to withstand vibration (30G) on request and for long-term stability
Buy the Panasonic EEEHA1A101WP – Reliable Aluminum Electrolytic Capacitors for Industrial Applications
Upgrade your electronic projects today by ordering the Panasonic aluminum electrolytic capacitor EEEHA1A101WP online. This high-quality surface mount capacitor offers excellent temperature endurance, low ESR, and vibration resistance, making it ideal for demanding environments. Whether for home appliances, optical equipment, or industrial electronics, this component guarantees reliable performance over long service life. Easy to install with compatible reflow soldering profiles, secure your supply chain now and ensure your devices operate efficiently and safely with Panasonic quality.
Order your Panasonic series aluminum electrolytic capacitor EEEHA1A101WP today and enhance your electronic device reliability with proven long-term stability and vibration resistance.
Frequently Asked Questions
Where can I buy Panasonic EEEHA1A101WP?
You can click on the BUY or RFQ button to purchase EEEHA1A101WP from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part EEEHA1A101WP?
You can download the EEEHA1A101WP datasheet or visit the Panasonic website for support.
Who is the manufacturer of EEEHA1A101WP?
Panasonic
