Panasonic EEUFM1E471L Aluminum Electrolytic Capacitor
The Panasonic FM series capacitors are radial leaded, polarized aluminum electrolytic capacitors of Type A. They have capacitance values ranging from 22µF to 6800µF. These capacitors are suitable for high ripple current applications, offering low impedance and long lifespan, with endurance from 2000 to 7000 hours at 105°C. They boast high reliability, rated voltages from 6.3V to 50V DC, and operate within a temperature range of -40°C to 105°C, compliant with RoHS standards for environmentally conscious use.
Panasonic EEUFM1E471L Aluminum Electrolytic Capacitor Specifications:
- Category Temperature Range: -40°C to +105°C
- Rated Voltage Range: 6.3 V DC to 50 V DC
- Capacitance Range: 22 µF to 6800 µF
- Capacitance Tolerance: ±20%
- DC Leakage Current: ≤ 10.01 CV (uA) after 2 minutes
- Endurance: 2000 to 7000 hours at +105°C
- Operating Temperature: -40°C to +105°C
- Impedance: 0.045 to 1.0 Ω at 100 kHz and +20°C depending on capacitance
- Physical Dimensions: Body diameter from 5 mm to 16 mm, length varies from 12.5 mm to 40 mm
- Lead Diameter: 0.5 mm to 0.8 mm, lead length minimum 20 mm
- RoHS compliant, not automotive rated
- Ripple Current: 250 mA to 3750 mA at +105°C depending on model
Buy the Panasonic Series FM Aluminum Electrolytic Capacitors: EEUFM1E471L
Purchase the Panasonic Series FM aluminum electrolytic capacitor EEUFM1E471L online today. Designed for high ripple current, low impedance, and long lifespan, this premium capacitor excels in demanding environments. Its robust construction ensures reliable performance at operate temperatures from -40°C to +105°C. Suitable for high-reliability electronics, power supplies, and industrial applications, this capacitor delivers exceptional endurance up to 7000 hours at 105°C. Order now to benefit from fast shipping and competitive prices.
Order your Panasonic Series FM aluminum electrolytic capacitor EEUFM1E471L today and enhance your electronic projects with high reliability and long-lasting performance.
Frequently Asked Questions
Where can I buy Panasonic EEUFM1E471L?
You can click on the BUY or RFQ button to purchase EEUFM1E471L from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part EEUFM1E471L?
You can download the EEUFM1E471L datasheet or visit the Panasonic website for support.
Who is the manufacturer of EEUFM1E471L?
Panasonic
