Panasonic ERJB1CFR05U High Power Chip Resistor
High power chip resistor with wide terminal construction designed for automotive and electronic circuit applications. Features excellent heat dissipation, reliable solder-joint connections, and compliance with AEC-Q200 and RoHS standards. Suitable for use in ECUs, air-bag systems, and current sensing in power supply circuits, providing stable performance under various environmental conditions.
Panasonic ERJB1CFR05U High Power Chip Resistor Specifications:
- Resistance values: 10mΩ to 10kΩ, 22mΩ to 1MΩ, depending on series
- Power ratings: 0.75W to 2W
- Resistance tolerance: ±1%, ±2%, ±5%
- Temperature range: -55°C to +125°C
- Maximum voltage: 70V to 400V depending on series
- Dimensions: Length varies from 2.5mm to 6.4mm, width from 0.25mm to 0.70mm
- Constructed with alumina substrate and thick film resistive elements
- RoHS and AEC-Q200 compliant
- Suitable for surface mounting on PCBs with precise land pattern and soldering conditions
- Operating in harsh environments, including automotive and industrial applications
Buy the Panasonic Series High Power Chip Resistors: ERJB1CFR05U
Purchase the Panasonic High Power Chip Resistor ERJB1CFR05U online today and ensure your electronic circuits perform reliably under demanding conditions. This wide terminal surface mount resistor features excellent heat dissipation, high mechanical strength, and industry-standard compliance for automotive and industrial applications. Designed with a robust alumina substrate and thick film resistive elements, it offers precise resistance values, excellent stability, and durability. Convenient online ordering guarantees quick delivery, enabling you to enhance your manufacturing process with top-quality, industry-approved resistors that meet global safety and environmental standards.
Order your Panasonic Series High Power Chip Resistors ERJB1CFR05U today and equip your automotive and industrial electronics with dependable heat dissipation and reliable operation.
Frequently Asked Questions
Where can I buy Panasonic ERJB1CFR05U?
You can click on the BUY or RFQ button to purchase ERJB1CFR05U from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ERJB1CFR05U?
You can download the ERJB1CFR05U datasheet or visit the Panasonic website for support.
Who is the manufacturer of ERJB1CFR05U?
Panasonic
