Panasonic ERJB1CFR068U High Power Chip Resistor
The high power chip resistor with wide terminal design is ideal for automotive electronic circuits, including ECUs, anti-lock braking, and airbag systems. It features excellent heat dissipation and solder-joint reliability, complying with AEC-Q200 standards and RoHS regulations. Its rugged construction allows for high ambient temperature operation and overload capacity, making it suitable for current sensing and power supply applications. Its dimensions are optimized for surface mounting, with robust construction ensuring long-term durability in demanding environments.
Panasonic ERJB1CFR068U High Power Chip Resistor Specifications:
- Resistance Range: 10mΩ to 10kΩ
- Resistance Tolerance: ±1%, ±2%, ±5%
- Power Rating: 1W, 2W, 0.75W
- Temperature Coefficient: ±100 to ±200 ppm/°C
- Maximum Operating Temperature: 125°C
- Rated Voltage: 200V to 400V depending on model
- Size: ERJA1, ERJB1, ERJB2, ERJB3 series dimensions detailed below
- Construction: Thick film resistive element on alumina substrate, wide terminal electrodes
- Compliance: AEC-Q200, RoHS
- Soldering Conditions: Peak temperature 270°C for 10s
- Packaging: Embossed carrier tape, 4000-5000 pcs per reel
- Environmental Resistance: Can withstand 1000 cycle temperature tests, humid aging, and load life testing
Buy the Buy Panasonic High Power Chip Resistors Wide Terminal Part Number ERJB1CFR068U Online
Purchase Panasonic high power chip resistors with wide terminal construction online today. These resistors are perfect for automotive circuits, current sensing, and power supply applications. Featuring excellent heat dissipation, high overload capacity, and compliance with AEC-Q200 standards, they ensure long-term durability in demanding environments. Available in various sizes with robust construction, RoHS compliance, and proven reliability through temperature cycles, humid aging, and load life testing. Order now for fast delivery and peace of mind in your electronic applications.
Get Panasonic ERJB1CFR068U high power chip resistor today—designed for automotive and high-temperature power sensing with long-lasting reliability and excellent heat dissipation.
Frequently Asked Questions
Where can I buy Panasonic ERJB1CFR068U?
You can click on the BUY or RFQ button to purchase ERJB1CFR068U from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ERJB1CFR068U?
You can download the ERJB1CFR068U datasheet or visit the Panasonic website for support.
Who is the manufacturer of ERJB1CFR068U?
Panasonic
