Panasonic ERJP14F1692U Anti-Surge Chip Resistor
The ERJP14F1692U is a high-reliability, anti-surge thick film chip resistor designed for demanding electronic applications. Featuring superior ESD surge characteristics and common industry standards compliance, it ensures stability and durability under various environmental stresses. Suitable for reflow and flow soldering, it provides high power ratings with a small form factor of 1210 inches. Ideal for circuits requiring high resistance values, high voltage, and precise tolerance control, the resistor offers excellent temperature stability and low noise. Its construction includes a metal glaze thick film resistive element with three layers of electrodes, making it suitable for automotive and industrial environments.
Panasonic ERJP14F1692U Anti-Surge Chip Resistor Specifications:
- Size: 1210 inches / 3225 mm
- Power Rating: 0.50 W
- Resistance Range: 10 to 10 MΩ
- Resistance Tolerance: +1 %
- TCR: +100 (× 10%/K)
- Voltage Limiting Element: 500 V
- Temperature Range: -55°C to +155°C (−55°C to +125°C for some models)
- Peak Overload Voltage: Based on rated voltage, 2.5s pulse
- Soldering: Suitable for reflow and flow soldering
- Material: Metal glaze thick film resistive element with electrode layers
- Compliance: IEC 60115-8, JIS C 5201-8, JEITA RC-2134C, RoHS, AEC-Q200
- Dimensions: Length 3.20mm, Width 2.50mm, Height 0.60mm
- ESD Characteristic: Up to 1.5kΩ for small sizes, R=0 to 1.5kΩ for others
- Construction includes alumina substrate, inner electrode, resistive element, and outer electrode
- Packaging: Embossed carrier tape, 5,000 pcs per reel
- Application: Automotive, industrial, high-voltage electronic circuits
Buy the Panasonic Series ERJ P: Anti-Surge Thick Film Chip Resistor 1210: ERJP14F1692U
Purchase the Panasonic Series ERJ P anti-surge thick film chip resistor online today for reliable performance in high-voltage and industrial applications. With a compact 1210 size, it supports reflow and flow soldering processes, offering high power ratings, precise resistance tolerance, and excellent temperature stability. Designed with a metal glaze thick film resistive element and three-layer electrodes, this resistor ensures superior ESD characteristics and durability across a wide temperature range. Whether for automotive, industrial, or high-voltage circuits, buy online now for fast delivery and trusted quality on every unit.
Order your Panasonic Series ERJ P high-power resistor today and give your electronic projects the dependable quality they deserve with superior surge resistance.
