Panasonic ERJUP6J101V Anti-Sulfurized Chip Resistor
This high-reliability, anti-sulfurated thick film chip resistor offers superior sulfurization resistance thanks to specialized electrode materials and structures. Designed for industrial and electronic applications, it features excellent ESD surge characteristics, making it suitable for environments with electrical disturbances. With power ratings up to 0.66 W in a 1206 size, it supports both reflow and flow soldering, complying with IEC 60115-8, JIS C 5201-8, EIAJ RC-2134B standards, and RoHS. Its robust construction ensures long-term stability in harsh conditions, including high temperatures and humidity, making it ideal for high-reliability electronic applications.
Panasonic ERJUP6J101V Anti-Sulfurized Chip Resistor Specifications:
- Resistance values range from 10Ω to 10MΩ (E24, E96 types)
- Power Ratings: 0.25 W for 0603, 0.50 W for 0805, 0.66 W for 1206
- Resistance Tolerance: ±0.5%, ±1%, ±5%
- Resistance Temperature Coefficient (TCR): within ±100 ppm/°C
- Operating Temperature Range: -55°C to +155°C
- Overload Voltage: 200 V (ERJUP3), 600 V (ERJUP6), 1000 V (ERJUP8)
- Rated Voltage at 70°C: 150 V (ERJUP3), 400 V (ERJUP6), 500 V (ERJUP8)
- Maximum Resistance Power: 0.25 W (0603), 0.50 W (0805), 0.66 W (1206)
- Compliance Standards: IEC 60115-8, JIS C 5201-8, EIAJ RC-2134B, AEC-Q200, RoHS
- Dimensions: 0603-0.15×0.85 mm, 0805-2.0×0.25 mm, 1206-3.2×0.16 mm
- Features: High sulfur resistance, anti-surge, metal glaze resistive element, three-layer electrodes, suitable for reflow and flow soldering
Buy the Panasonic ERJUP6 – Reliable Anti-Surge Resistors for Industrial Applications
Enhance your electronic systems with Panasonic's anti-sulfurized thick film chip resistor, designed for high reliability and superior surge resistance. Available in multiple sizes with power ratings up to 0.66 W, these resistors are resistant to sulfurization, ensuring stable performance in harsh environments. Suitable for reflow and flow soldering, they meet international standards including IEC, JIS, and RoHS. Add these robust resistors to your inventory for dependable operation in industrial, automotive, and high-reliability electronic equipment.
Buy Panasonic ERJUP6 now and experience unmatched reliability and high sulfur resistance ideal for demanding industrial environments.
Frequently Asked Questions
Where can I buy Panasonic ERJUP6J101V?
You can click on the BUY or RFQ button to purchase ERJUP6J101V from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ERJUP6J101V?
You can download the ERJUP6J101V datasheet or visit the Panasonic website for support.
Who is the manufacturer of ERJUP6J101V?
Panasonic
