Panasonic EVPAVAA1A Light Touch Switch
The Panasonic EVP-AVAA1A is a miniature SMD light touch switch engineered for integration into portable electronic devices such as mobile phones and digital cameras. Its compact 3.5mm x 2.9mm footprint and low 1.7mm height make it ideal for space-constrained applications. The switch provides a high operating force (up to 7.0 N) and incorporates an optional ground terminal for improved noise immunity. It is designed for reliable snap-action performance and is suitable for keyless entry systems and other applications requiring a momentary push-on/push-off action. Always consult the latest product specifications before purchase and/or use.
Panasonic EVPAVAA1A Light Touch Switch Specifications:
- External dimensions: 3.5 mm×2.9 mm, Height 1.7 mm
- Operating force: 7.0 N max.
- Type: Snap action/Push-on type SPST
- Electrical Rating: 10 μA 2 V DC to 20 mA 15 V DC (Resistive load)
- Contact Resistance: 100 mΩ max.
- Insulation Resistance: 100 MΩ min. (at 100 V DC)
- Dielectric Withstanding Voltage: 250 V AC for 1 minute
- Bouncing: 10 ms max. (ON, OFF)
- Operating Force Options: 1.0 N, 1.6 N, 2.4 N, 3.5 N, 5.0 N, 7.0 N
- Travel: 0.15 mm±0.1 mm
- Operating Life: 1,000,000 cycles min. (1.0 N), 500,000 cycles min. (3.5 N), 200,000 cycles min. (1.6 N, 2.4 N, 3.5 N, 5.0 N), 100,000 cycles min. (5.0 N, 7.0 N)
- Operating Temperature: –40 °C to +85 °C
- Storage Temperature: –40 °C to +85 °C (Bulk), –20 °C to +60 °C (Taping)
- Minimum Quantity/Packing Unit: 5,000 pcs. Embossed Taping (Reel Pack)
- Quantity/Carton: 25,000 pcs.
Buy the EVP-AVAA1A PANASONIC Light Touch Switch | myMectronic
Securely purchase the Panasonic EVP-AVAA1A Light Touch Switch online for reliable performance and fast delivery.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic EVPAVAA1A?
You can click on the BUY or RFQ button to purchase EVPAVAA1A from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part EVPAVAA1A?
You can download the EVPAVAA1A datasheet or visit the Panasonic website for support.
Who is the manufacturer of EVPAVAA1A?
Panasonic
