Panasonic ST1DC12VF Power Relay
The ST1-DC12V-F is a polarized power relay with a DC coil, featuring one form-A and one form-B Au-flashed AgSnO₂ contacts. This relay provides high contact pressure, low contact bounce, and a forced separation structure that significantly enhances resistance to contact welding. It achieves a high breakdown voltage of 3750Vrms between contacts and coil, with surge breakdown voltages of 6000V between coil and contact, and 1200Vrms between open contacts, making it suitable for controlling 250V power circuits. Additional features include single-side stable operation, sensitivity suitable for direct IC driving despite its compact size, high switching capacity, automatic cleaning capability, and easy PCB design. It is ideal for industrial applications.
Panasonic ST1DC12VF Power Relay Specifications:
- Arrangement: 1 Form A 1 Form B, 2 Form A
- Contact Material: Au-flashed AgSnO₂
- Max. Switching Power: 3,040 VA, 150 W
- Max. Switching Voltage: 380 VAC, 250 VDC
- Max. Switching Current: 8A
- Insulation Resistance: Min. 1,000 MΩ at 500V DC
- Breakdown Voltage: 3750 Vrms between contact and coil; Surge 6000 V between coil and contact; 1200 Vrms between open contacts
- Operate Time: Nominal, excluding contact bounce
- Release Time: Nominal, excluding contact bounce
- Electrical & Mechanical Life: Min. 107 cycles
- Unit Weight: Approx. 10g
Buy the Buy Panasonic Relay Part Number ST1DC12VF Online
Purchase the Panasonic power relay ST1-DC12V-F online today and benefit from its high contact pressure, excellent dielectric strength, automatic cleaning, and robust design. It is ideal for controlling 250V power circuits in industrial applications, with a high switching capacity of 3,040 VA. Its compact form supports easy PCB integration, and the relay’s high breakdown voltage ensures safety and durability in demanding environments. Conveniently order online for reliable and efficient circuit control solutions.
Get Panasonic ST1DC12VF relay today—designed for high reliability, high switching capacity, and automatic cleaning for industrial automation needs.
