Panasonic TQ23V Signal Relay
This signal relay features a 3 V DC coil voltage, a Double Pole Double Throw DPDT contact configuration, and a maximum switching current of 1 Amp. Designed for PCB mounting, it operates on a single side stable switching function, offering high sensitivity and surge voltage withstand capability of 1500 V. The relay includes sealed construction suitable for automatic washing, self-clinching terminals, and MBB contact types, making it ideal for reliable circuit control in industrial and electronic applications.
Panasonic TQ23V Signal Relay Specifications:
- Coil Voltage: 3 V DC
- Contact Configuration: Double Pole Double Throw (DPDT)
- Maximum Switching Current: 1 A
- Operating Function: Single side stable
- Surge Voltage Withstand: 1500 V
- Mounting Type: PCB
- Construction: Sealed for automatic washing
- Contact Material: Gold-clad silver
- Contact Types Available: MBB
- Operating Temperature Range: -40°C to +70°C
- Vibration Resistance: at 3 mm amplitude, 10 to 55 Hz
- Shock Resistance: Functional 50G, Destructive 100G
- Temperature Rise: Max. 50°C at 20°C ambient
- Weight: Approximately 10 grams
- RoHS Compatible: Yes
Buy the Buy Panasonic Signal Relay Part Number TQ23V Online
Order the Panasonic TQ23V Signal Relay online today to ensure your electronic projects or industrial equipment benefit from high sensitivity, robust construction, and reliable operation. Enjoy quick delivery and competitive prices by purchasing now. This relay offers excellent surge voltage tolerance, sealed design for washing, and is perfect for PCB mounting, making it an essential component for dependable circuit switching. Upgrade your manufacturing or repair system today with trusted quality and performance.
Buy Panasonic TQ23V now and experience reliable circuit control with high sensitivity and durable construction for industrial applications.
Frequently Asked Questions
Where can I buy Panasonic TQ23V?
You can click on the BUY or RFQ button to purchase TQ23V from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part TQ23V?
You can download the TQ23V datasheet or visit the Panasonic website for support.
Who is the manufacturer of TQ23V?
Panasonic
