Panduit LCAX4012X Flex Conductor Lug
The Panduit LCAX4/0-12-X flex conductor lug provides a secure and reliable connection for flexible, extra-flexible, and code stranded copper conductors. Its design incorporates a generously beveled wire entry to prevent bent back strands during insertion, ensuring a consistent and quality crimp. The inspection window allows for visual confirmation of full conductor insertion, enhancing the reliability of the connection. Color-coded barrels simplify die selection, and the lug is tin-plated to inhibit corrosion. This connector is ideal for applications requiring robust and dependable electrical connections in industrial environments.
Panduit LCAX4012X Flex Conductor Lug Specifications:
- conductor_size: 4/0 AWG
- class: G, H, I, K, M, Diesel Locomotive
- stud_hole_size: 1/2 In.
- figure_dimensions_w: 0.41
- figure_dimensions_b: 0.42
- figure_dimensions_t: 0.08
- figure_dimensions_l: 1.11
- panduit_color_code: Gray
- panduit_die_index_no: P29
- burndy_die_index_no: 8
- t_and_b_die_index_no: 29
- wire_strip_length: 5/8
- std_pkg_qty: 50
- ul_listed: Yes
- csa_certified: Yes
- temperature_rating: 90°C
