Panduit NK5EPP48P Category 5e Punchdown Patch Panel
The Panduit NK5EPP48P Category 5e Punchdown Patch Panel provides a robust and standardized solution for terminating network cables. Designed to mount in standard TIA/EIA 19" or 23" racks, this panel supports 22-26 AWG, 100 ohm cable. It meets stringent industry standards including TIA/EIA-568-C.2, ISO 11801, and IEEE 802.3af/at for PoE applications. The angled design option facilitates bend radius control and simplifies cable management, making it suitable for a wide range of network applications including Ethernet, ATM, and VoIP.
Panduit NK5EPP48P Category 5e Punchdown Patch Panel Specifications:
- Category: Category 5e/Class D
- Meets Standards: TIA/EIA-568-C.2, ISO 11801
- Channel Performance: Up to 100 MHz
- FCC Compliance: ANSI/TIA-968-A, 50 microinches gold plating
- IEC Compliance: IEC 60603-7
- PoE Compliance: IEEE 802.3af and IEEE 802.3at
- UL Rating: UL 1863 approved
- Mounting Options: Standard EIA 19" or 23" racks
- Performance Tested: 100% performance tested
- Termination Style: 110 style with retention cap
- Identification: Write-on areas for port and panel identification
- Industry Standard: Backwards compatible
- Angled Design: Facilitates bend radius control
- Applications: Ethernet, ATM, Token Ring, VoIP
Buy the NK5EPP48P PANDUIT Category 5e Punchdown Patch Panel | myMectronic
Securely purchase the Panduit NK5EPP48P online for reliable network connectivity.
Buy Now
Frequently Asked Questions
Where can I buy Panduit NK5EPP48P?
You can click on the BUY or RFQ button to purchase NK5EPP48P from an authorized Panduit distributor.
How do I troubleshoot issues or seek technical support for part NK5EPP48P?
You can download the NK5EPP48P datasheet or visit the Panduit website for support.
Who is the manufacturer of NK5EPP48P?
Panduit
