Phoenix Contact 1411926 M12 SMD Connector
The Phoenix Contact SACC-CI-M12MS-5P SMD T (part number 1411926) is a compact and robust flush-type connector specifically engineered for surface-mount device (SMD) PCB applications. This 5-position M12 connector utilizes PlugLink technology for simplified and secure connections. Key features include reduced mounting costs thanks to its two-piece design, compatibility with automated pick-and-place assembly processes, and versatile mounting options including mechanical port screw connections, threaded attachment, press-in contours, or direct front plate integration. The connector's robust construction and IP67 degree of protection make it suitable for demanding industrial environments. It is commonly used in automation, industrial networking, and sensor applications where a reliable and compact M12 connection is required.
Phoenix Contact 1411926 M12 SMD Connector Specifications:
- Packing unit: 60 STK
- Minimum order quantity: 60 STK
- GTIN: 4046356990042
- Weight per Piece (excluding packing): 4.040 g
- Custom tariff number: 85366990
- Country of origin: Germany
- Note: Made to Order (non-returnable)
- Ambient temperature (operation): -55 °C ... 105 °C
- Degree of protection: IP67
- Rated current at 40°C: 4 A
- Rated voltage: 60 V
- Rated surge voltage: 1.5 kV
- Number of positions: 5
- Insulation resistance: ≥ 100 MΩ
- Coding: A - standard
- Standards/regulations: M12 connector IEC 61076-2-101
- Overvoltage category: III
- Degree of pollution: 3
- Connection method: SMD
- Insertion/withdrawal cycles: > 100
- Mounting type: PCB mounting
- Type of packaging: Tray
- Delivery state: with assembly pad
- Flammability rating according to UL 94: V0
- Contact material: CuZn
- Contact surface material: Au
- Contact carrier material: PA
- Standards and Regulations: M12 connector IEC 61076-2-101
- Standard designation: M12 connector
- China RoHS: Environmentally Friendly Use Period = 50
