Phoenix Contact 1703496 Feed-through connector
This connector is a green feed-through component designed for robust electrical applications, rated for 76 A and 1000 V, suitable for PCB and industrial wiring. It has six connection positions with 10.16 mm pitch, supporting 2 conductors with same cross section, stranded, ferrules without plastic sleeve, and TWIN ferrules with plastic sleeve, max 6 mm. Installation is quick via snap-lock or screw, compatible with panel thickness 1-3 mm. The high-quality silver-plated contact surface ensures excellent conductivity and durability in demanding environments.
Phoenix Contact 1703496 Feed-through connector Specifications:
- Rated current: 76 A
- Rated voltage: 1000 V (Type III/2)
- Number of positions: 6
- Pitch: 10.16 mm
- Connection method: Screw with tension sleeve
- Contact surface: Silver-plated
- Panel thickness: 1 mm to 3 mm
- Conductor cross section: 0.5 mm² to 6 mm²
- Compatibility: Feed-through headers for PC 16 plugs
- Standards: EN-VDE compliant
- Approvals: UL Recognized, cUL Recognized, SEV, EAC, CB Scheme
- Dimensions: Approximate length 93.5 mm, width 30.55 mm
Buy the Phoenix Contact 1703496 – Reliable Feed-Through Connector for Industrial Applications
Purchase the Phoenix Contact feed-through connector online today for a reliable and durable solution to your industrial wiring needs. Designed with high-quality materials, it features a silver-plated contact surface for excellent conductivity, support for a maximum current of 76 A and voltage of 1000 V. Its quick installation via snap-lock or screw ensures operational efficiency. Suitable for panel thickness 1-3 mm and compatible with PC 16 headers, this connector guarantees secure and efficient electrical connections in demanding environments. Order now for fast delivery and peace of mind.
Get Phoenix Contact 1703496 today—built for precision and long-lasting durability in industrial wiring solutions.
Frequently Asked Questions
Where can I buy Phoenix Contact 1703496?
You can click on the BUY or RFQ button to purchase 1703496 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1703496?
You can download the 1703496 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1703496?
Phoenix Contact
