Phoenix Contact 1704857 4 Position Plug Connector
The Phoenix Contact 1704857 plug connector is a miniature component ideal for applications requiring a compact and reliable connection. Designed with a 2.5mm pitch, it's compatible with both THR (Through-Hole Reflow) and SMD (Surface Mount Device) base strips, providing versatility in assembly. The push-in spring connection ensures easy and secure termination of conductors, while the white housing and tin-plated contacts contribute to durability and corrosion resistance. This connector is commonly used in industrial automation, control systems, and power distribution panels where space is limited and reliable connections are essential.
Phoenix Contact 1704857 4 Position Plug Connector Specifications:
- Nominal current: 6 A
- Rated voltage (III/2): 160 V
- Number of positions: 4
- Pitch: 2.5 mm
- Connection method: Push-in spring connection
- Color: white
- Contact surface: Tin
- Insulating material group: I
- Rated surge voltage (III/3): 2.5 kV
- Rated surge voltage (III/2): 2.5 kV
- Rated surge voltage (II/2): 2.5 kV
- Rated voltage (III/3): 100 V
- Rated voltage (II/2): 320 V
- Connection in acc. with standard: EN-VDE
- Nominal cross section: 0.5 mm²
- Maximum load current: 6 A
- Insulating material: HT PA
- Flammability rating according to UL 94: V0
- Stripping length: 6 mm
- Conductor cross section solid min.: 0.14 mm²
- Conductor cross section solid max.: 0.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 0.5 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 0.5 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 20
- Minimum AWG according to UL/CUL: 26
- Maximum AWG according to UL/CUL: 20
- eCl@ss 4.0: 272607xx
- eCl@ss 4.1: 27260701
- eCl@ss 5.0: 27260701
- eCl@ss 5.1: 27141190
- eCl@ss 6.0: 27260704
- eCl@ss 7.0: 27440402
- eCl@ss 8.0: 27440402
- eCl@ss 9.0: 27440402
- ETIM 3.0: EC001121
- ETIM 4.0: EC002638
- ETIM 5.0: EC002637
- UNSPSC 6.01: 30211810
- UNSPSC 7.0901: 39121409
- UNSPSC 11: 39121409
- UNSPSC 12.01: 39121409
- UNSPSC 13.2: 39121409
- Length: 15 mm
- Height: 5 mm
- Dimension a: 7.5 mm
- Weight per Piece (excluding packing): 1.12 g
- Custom tariff number: 85369010
- Country of origin: Poland
Buy the 1704857 PHOENIX CONTACT 4 Position Plug Connector | myMectronic
Securely purchase the Phoenix Contact 1704857 plug connector online for reliable and efficient component procurement.
Buy Now
Frequently Asked Questions
Where can I buy Phoenix Contact 1704857?
You can click on the BUY or RFQ button to purchase 1704857 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1704857?
You can download the 1704857 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1704857?
Phoenix Contact
