Phoenix Contact 1743184 PCB Terminal Block
The PHOENIX CONTACT SPTA 1,5/ 7-3,81 PCB terminal block is a versatile solution for connecting wires to printed circuit boards. Its 3.81mm pitch and 7-position configuration make it suitable for a variety of applications. The push-in spring connection simplifies conductor termination, while the orange actuating lever allows for easy release. The classic desk shape with double pinning enhances operational safety, and large cable funnels accommodate conductors up to 1.5 mm². This terminal block is ideal for applications requiring reliable and efficient PCB connections, particularly in industrial automation and control systems.
Phoenix Contact 1743184 PCB Terminal Block Specifications:
- Nominal current: 9 A
- Nominal voltage: 160 V
- Pitch: 3.81 mm
- Number of positions: 7
- Connection method: Push-in spring connection
- Mounting: Wave soldering
- Conductor/PCB connection direction: 45 °
- Color: green
- Packing unit: 1 pc
- Minimum order quantity: 50 pc
- Weight per Piece: 4.01 g
- Custom tariff number: 85369010
- Country of origin: Germany
- Dimension a: 22.86 mm
- Length of the solder pin: 3.4 mm
- Pin dimensions: 0,6 x 1,0 mm
- Pin spacing: 7 mm
- Hole diameter: 1.1 mm
- Range of articles: SPTA 1,5/
- Insulating material group: I
- Rated surge voltage III/3: 2.5 kV
- Rated surge voltage III/2: 2.5 kV
- Rated surge voltage II/2: 2.5 kV
- Rated voltage III/3: 160 V
- Rated voltage III/2: 160 V
- Rated voltage II/2: 320 V
- Connection in acc. with standard: EN-VDE
- Nominal cross section: 1.5 mm²
- Maximum load current: 9 A
- Insulating material: PA
- Solder pin surface: Sn
- Flammability rating according to UL 94: V0
- Stripping length: 10 mm
- Conductor cross section solid min.: 0.2 mm²
- Conductor cross section solid max.: 1.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 1.5 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 1.5 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve max.: 1.5 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 16
- eCl@ss 4.0: 27141109
- eCl@ss 4.1: 27141109
- eCl@ss 5.0: 27141190
- eCl@ss 5.1: 27141190
- eCl@ss 6.0: 27261101
- eCl@ss 7.0: 27440401
- eCl@ss 8.0: 27440401
- ETIM 3.0: EC001121
- ETIM 4.0: EC002643
- ETIM 5.0: EC002643
- UNSPSC 6.01: 30211801
- UNSPSC 7.0901: 39121432
- UNSPSC 11: 39121432
- UNSPSC 12.01: 39121432
- UNSPSC 13.2: 39121432
