Phoenix Contact 1768817 PCB connector
This PCB connector features a nominal current of 12 A and a rated voltage of 320 V, designed for 2.5 mm² conductors with 7 contact positions. It has a pitch of 5 mm and uses a screw connection with a tension sleeve for secure installation. The connector's green body and tin-plated contact surface ensure reliable and corrosion-resistant electrical connections. Certified for CSA, UL recognition, and other global standards, it is ideal for industrial automation and circuit board applications requiring high current capacity and precise configuration.
Phoenix Contact 1768817 PCB connector Specifications:
- Nominal current: 12 A
- Rated voltage: 320 V (III/2)
- Number of positions: 7
- Pitch: 5 mm
- Connection method: Screw connection
- Contact surface: Tin-plated
- Color: Green
- Material: Insulated body (green)
- Conductor cross-section: 2.5 mm²
- Approvals: CSA Recognized, UL Recognized, cUL Recognized
- Rated voltage in approvals: 300 V
- Suitable for stranded conductors with ferrules
- Contact surface: Tin
- Assembly: Solder/Slip-on or Press-in options
- Dimensions: Compact design suitable for PCB mounting
Buy the Phoenix Contact Series SMSTB PCB Connector: 1768817
Secure your electrical connections with the Phoenix Contact Series SMSTB 2,5/ 7-ST PCB connector, featuring 7 contact positions, 12 A current capacity, and a 320 V rated voltage. Its screw connection provides a secure fit, while the tin-plated contact surface ensures corrosion resistance. The green body aligns with industry standards for safety and durability in industrial and circuit board applications. Easy to install with options for solder, slip-on, or press-in assembly, this connector guarantees high reliability and efficient electrical performance in demanding environments.
Order your Phoenix Contact Series SMSTB 2,5/ 7-ST PCB connector today and ensure reliable, high-current circuit connections for your industrial projects.
Frequently Asked Questions
Where can I buy Phoenix Contact 1768817?
You can click on the BUY or RFQ button to purchase 1768817 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1768817?
You can download the 1768817 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1768817?
Phoenix Contact
