Phoenix Contact 1777765 PCB Connector
The Phoenix Contact 1777765 is a 6-position printed-circuit board connector designed for secure and reliable connections in industrial applications. It utilizes a screw connection with a tension sleeve, ensuring a stable and durable connection. The connector's low temperature rise and maximum contact force contribute to its performance and longevity. It is suitable for connecting two conductors and incorporates a double steel spring for added safety against temperature and power fluctuations. With UL approval and a wide range of supported conductor sizes, this connector provides a versatile solution for various electronic assemblies.
Phoenix Contact 1777765 PCB Connector Specifications:
- Packing unit: 1 STK
- Minimum order quantity: 50 STK
- GTIN: 4046356522908
- Weight per Piece (excluding packing): 26.800 g
- Custom tariff number: 85366990
- Country of origin: Germany
- Length [ l ]: 35.3 mm
- Width [ w ]: 45.67 mm
- Height [ h ]: 19.7 mm
- Pitch: 7.62 mm
- Dimension a: 38.1 mm
- Range of articles: PC 5/..-ST1
- Type of contact: Female connector
- Number of positions: 6
- Connection method: Screw connection with tension sleeve
- Insulating material group: I
- Rated surge voltage (III/3): 8 kV
- Rated surge voltage (III/2): 8 kV
- Rated surge voltage (II/2): 6 kV
- Rated voltage (III/3): 1000 V
- Rated voltage (III/2): 1000 V
- Rated voltage (II/2): 1000 V
- Nominal current IN: 41 A
- Nominal cross section: 6 mm²
- Maximum load current: 41 A
- Insulating material: PA
- Flammability rating according to UL 94: V0
- Internal cylindrical gage: A4
- Stripping length: 10 mm
- Screw thread: M3
- Tightening torque, min: 0.5 Nm
- Tightening torque max: 0.8 Nm
- Conductor cross section solid min.: 0.2 mm²
- Conductor cross section solid max.: 10 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 6 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 6 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve max.: 4 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 10
- 2 conductors with same cross section, solid min.: 0.2 mm²
- 2 conductors with same cross section, solid max.: 2.5 mm²
- 2 conductors with same cross section, stranded min.: 0.2 mm²
- 2 conductors with same cross section, stranded max.: 4 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve min.: 0.25 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve max.: 1.5 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve min.: 0.25 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve max.: 2.5 mm²
- Minimum AWG according to UL/CUL: 24
- Maximum AWG according to UL/CUL: 8
- China RoHS: Environmentally Friendly Use Period = 50
