Phoenix Contact 1777846 PCB Connector
The PHOENIX CONTACT PC 5/ 3-STF1-7,62 connector is a high-quality PCB connector designed for demanding industrial applications. It offers a secure screw connection with a tension sleeve, ensuring reliable electrical contact. The connector's robust construction, combined with its low temperature rise and integrated double steel spring, provides exceptional stability and performance even under fluctuating temperatures and power conditions. It is suitable for a wide range of applications requiring high current carrying capacity and mechanical strength, such as power distribution, automation, and control systems.
Phoenix Contact 1777846 PCB Connector Specifications:
- Nominal current: 41 A
- Number of positions: 3
- Pitch: 7.62 mm
- Connection method: Screw connection with tension sleeve
- Color: green
- Contact surface: Tin
- Length: 35.5 mm
- Width: 38.09 mm
- Height: 19.7 mm
- Range of articles: PC 5/..-STF1
- Insulating material group: I
- Rated surge voltage (III/3): 8 kV
- Rated surge voltage (III/2): 8 kV
- Rated surge voltage (II/2): 6 kV
- Rated voltage (III/3): 1000 V
- Rated voltage (III/2): 1000 V
- Rated voltage (II/2): 1000 V
- Nominal cross section: 6 mm²
- Maximum load current: 41 A
- Insulating material: PA
- Flammability rating: V0
- Stripping length: 10 mm
- Screw thread: M3
- Tightening torque (min): 0.5 Nm
- Tightening torque (max): 0.8 Nm
- Conductor cross section solid (min): 0.2 mm²
- Conductor cross section solid (max): 10 mm²
- Conductor cross section flexible (min): 0.2 mm²
- Conductor cross section flexible (max): 6 mm²
- Conductor cross section flexible with ferrule (min): 0.25 mm²
- Conductor cross section flexible with ferrule (max): 6 mm²
- Conductor cross section AWG (min): 24
- Conductor cross section AWG (max): 10
- Minimum AWG: 24
- Maximum AWG: 8
- Packing unit: 1 pc
- Minimum order quantity: 50 pc
- Custom tariff number: 85366990
- Country of origin: Germany
- REACh SVHC: Lead 7439-92-1
- China RoHS: Environmentally Friendly Use Period = 50
