Phoenix Contact 1777914 PCB Terminal Block
Phoenix Contact PC 5/10-STF1-762 is a terminal block designed for secure and reliable electrical connections. Suitable for industrial wiring applications, it features a compact design with screw termination for robust contact. The product supports 10 positions with a pitch of 7.62 mm, has a contact surface of Tin, and a maximum current of 41 A. Its dimensions include a length of 35.5 mm, width of 91.43 mm, and height of 19.7 mm. Certified for UL and cUL, this connector ensures safety and high performance in industrial environments.
Phoenix Contact 1777914 PCB Terminal Block Specifications:
- Number of positions: 10
- Pitch: 7.62 mm
- Rated current: 41 A
- Rated voltage: 1000 V
- Dimensions: Length 35.5 mm, Width 91.43 mm, Height 19.7 mm
- Contact surface: Tin
- Connection method: Screw with tension sleeve
- Insulating material: PA
- Flammability rating: UL 94 V-0
- Tightening torque: 0.5 to 0.8 Nm
- Conductor cross section: solid 0.2 - 10 mm², AWG 24 - 10
- Standards: UL, cUL recognized
- Approvals: EAC, cULus
Buy the Phoenix Contact PC 5/10-STF1-7,62 – Reliable PCB Terminal Block for Industrial Applications
Enhance your industrial wiring with the Phoenix Contact PCB Terminal Block. Featuring 10 positions, screw connection, and UL approval, it guarantees secure connections and high durability. The compact design fits readily into tight spaces, supporting conductors from 0.2 to 10 mm². Ideal for automation, control panels, and machinery, this terminal block ensures safety, ease of installation, and reliable operation. Purchase online today to streamline your electrical projects with top-quality components designed for demanding industrial environments.
Buy Phoenix Contact PC 5/10-STF1-7,62 now and experience unmatched reliability and performance for your industrial wiring and connection needs.
Frequently Asked Questions
Where can I buy Phoenix Contact 1777914?
You can click on the BUY or RFQ button to purchase 1777914 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1777914?
You can download the 1777914 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1777914?
Phoenix Contact
