Phoenix Contact 1788127 DIN rail connector
This DIN rail connector supports a nominal current of 12 A and rated voltage of 320 V category III/2. It features three positions with a pitch of 5.08 mm, allowing secure and reliable electrical connections. The connection method uses screw terminals with tension sleeves, ensuring a stable and corrosion-resistant contact. The green-colored component has a tin-plated contact surface for enhanced durability, and it’s designed for mounting on DIN rails, making it ideal for industrial automation, control panels, and electrical distribution systems.
Phoenix Contact 1788127 DIN rail connector Specifications:
- Nominal current: 12 A
- Rated voltage: 320 V (category III/2)
- Number of positions: 3
- Pitch: 5.08 mm
- Connection method: Screw connection with tension sleeve
- Color: Green
- Contact surface: Tin-plated
- Mounting: DIN rail
- Cross section: 2.5 mm²
- Standards: EN-VDE compliance
- CSA / UL Recognized
- VDE Certification
- Approvals: CSA, UL, cUL, EAC
- Dimensions: Compatible with NS 32 or NS 35 DIN rails
- Weight per piece: 11.43 g
Buy the Buy Phoenix Contact DIN Rail Connector Part Number 1788127 Online
Discover the convenience of purchasing the Phoenix Contact DIN rail connector online. With its robust screw connection, 12 A current capacity, and wide compatibility with DIN rails, this green-plated contact ensures secure and durable electrical connections. Ideal for automation and control systems, it combines easy installation and high durability. Order now to enhance your electrical projects with reliable, certified components designed for optimal performance and safety. Buy Phoenix Contact 1788127 and ensure your electrical connections are secure and compliant.
Buy Phoenix Contact 1788127 now and experience unmatched reliability and performance in industrial automation and electrical distribution.
Frequently Asked Questions
Where can I buy Phoenix Contact 1788127?
You can click on the BUY or RFQ button to purchase 1788127 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1788127?
You can download the 1788127 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1788127?
Phoenix Contact
