Phoenix Contact 1788169 DIN rail connector
This DIN rail connector supports a nominal current of 12 A and a rated voltage of 320 V (III/2). It features 7 positions with a pitch of 5.08 mm, accommodating 2 conductors with same cross section, stranded, ferrules without plastic sleeve, min. 0.25 mm², max. 4 mm². Utilizes screw connection with tension sleeve for secure wiring, in green color with tin-plated contact surface. Designed for DIN rail mounting on NS 32 or NS 35, providing reliable, easy installation in electrical systems.
Phoenix Contact 1788169 DIN rail connector Specifications:
- Nominal current: 12 A
- Rated voltage: 320 V (III/2)
- Number of positions: 7
- Pitch: 5.08 mm
- Connection method: Screw connection with tension sleeve
- Color: Green
- Contact surface: Tin
- Mounting: DIN rail
- Conductor cross section: 0.25 mm² to 4 mm², stranded, ferrules without plastic sleeve
- Standards and Regulations: EN-VDE
- Approvals: CSA / UL Recognized, VDE, cUL Recognized, IEC Scheme, EAC
- Dimensions: Fits NS 32 or NS 35 DIN rails
- Rated voltage (UL): 250 V
- Rated voltage (CSA): 300 V
- Maximum conductor size (AWG): 30-12
- Construction: Compact plug-in block for secure electrical connections
Buy the Buy Phoenix Contact Connector Part Number 1788169 Online
Order the Phoenix Contact DIN rail connector part number 1788169 online today to ensure secure and reliable electrical connections. This 7-position connector with a 5.08 mm pitch supports 12 A current and 320 V rated voltage, making it ideal for efficient electrical system wiring. The screw connection with tension sleeve ensures a solid, vibration-resistant fit. Easy to install on NS 32 or NS 35 DIN rails, its green color and tin-plated contact surface provide corrosion resistance and long-term reliability. Perfect for industrial, automation, control panels, or electrical installations, this connector guarantees safe, secure, and efficient wiring in your electrical systems.
Buy Phoenix Contact 1788169 connector now and experience unmatched reliability and performance in your DIN rail wiring solutions.
Frequently Asked Questions
Where can I buy Phoenix Contact 1788169?
You can click on the BUY or RFQ button to purchase 1788169 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1788169?
You can download the 1788169 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1788169?
Phoenix Contact
