Phoenix Contact 1826319 PCB connector
This green printed-circuit board connector features a screw connection with tension sleeves, five positions, and a pitch of 5.08 mm. It supports a maximum load current of 12 A and a rated voltage of 320 V category III/2. The connector is suitable for stranded conductors, including ferrules without plastic sleeves, with a cross-section range of 0.25 mm² to 4 mm². It complies with standards such as EN-VDE and is recognized by CSA, EAC, and cULus. The contact surface is tin-plated, ensuring reliable electrical connections in industrial and electronic applications.
Phoenix Contact 1826319 PCB connector Specifications:
- Type: PCB connector with screw connection
- Number of positions: 5
- Pitch: 5.08 mm
- Maximum load current: 12 A
- Rated voltage: 320 V category III/2
- Contact surface: Tin-plated
- Cross-section range: 0.25 mm² to 4 mm² (ferrules without plastic, stranded)
- Standards: EN-VDE compliant
- Approvals: CSA, EAC, cULus Recognized
- Ambient temperature range: -40°C to +85°C
- Color: Green
- Connection method: Tension sleeve screw
- Material: Insulating body made of durable plastic
- Suitable for industrial automation and electronic circuits
Buy the Phoenix Contact 1826319 – Reliable PCB Connectors for Industrial Applications
Discover the reliable PCB connector with five positions, screw connection, and tin-plated contacts, perfect for industrial automation. Featuring a 5.08 mm pitch and supporting up to 12 A current at 320 V, this connector ensures secure, efficient electrical connections for control panels, circuit boards, and automation systems. Its green insulation body makes installation straightforward, and compliance with standards such as EN-VDE and recognized approvals guarantee safety and reliability. Ideal for engineers and technicians seeking high-quality, durable PCB connectors online.
Get Phoenix Contact 1826319 today—built for precision, durability, and seamless electrical connections in industrial environments.
Frequently Asked Questions
Where can I buy Phoenix Contact 1826319?
You can click on the BUY or RFQ button to purchase 1826319 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1826319?
You can download the 1826319 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1826319?
Phoenix Contact
