Phoenix Contact 1827240 PCB Connector
This PCB connector features a nominal current of 8 A and a rated voltage of 160 V (category III/2). It has 14 positions with a pitch of 3.81 mm and a nominal cross section of 1.5 mm². The connection is made via screw terminals with tension sleeves. It is colored green and has a tin-plated contact surface for reliable electrical connection. Designed for compact and efficient PCB wiring, it includes individual position coding options, generous wiring space, and complies with various international standards and approvals for safety and quality in electrical connections.
Phoenix Contact 1827240 PCB Connector Specifications:
- Nominal current: 8 A
- Rated voltage: 160 V
- Number of positions: 14
- Pitch: 3.81 mm
- Connection method: Screw connection with tension sleeve
- Color: Green
- Contact surface: Tin-plated
- Width: 53.83 mm
- Dimension a: 49.53 mm
- Conductor cross section: 0.2-1.5 mm² (AWG 28-16)
- Rated voltage (UL): 300 V
- Ambient temperature range: -55°C to +85°C
- Standards and approvals: CSA, VDE, EAC, cULus, IEC schemes
Buy the Phoenix Contact Series MCVR PCB Connector: 1827240
Order the Phoenix Contact PCB connector today to ensure robust electrical connections in your projects. Featuring 14 positions, a 3.81 mm pitch, and a current capacity of 8 A, this connector is ideal for PCB wiring. Its screw terminal connection with tension sleeve guarantees secure contact, while the green color provides easy identification. Made with tin-plated contacts for longevity, it supports various standards and approvals, making it a reliable choice for industrial and electronic applications. Buy online now for fast delivery and competitive pricing.
Buy Phoenix Contact MCVR 1827240 now and experience unmatched reliability and performance with durable screw connection and compact design.
Frequently Asked Questions
Where can I buy Phoenix Contact 1827240?
You can click on the BUY or RFQ button to purchase 1827240 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1827240?
You can download the 1827240 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1827240?
Phoenix Contact
