Phoenix Contact 2908286 Energy Meter
The EEM-MA771 is a multi-functional energy measuring device with a direct Rogowski coil connection and an integrated Modbus/TCP interface, suitable for accurate electrical parameter measurements in low-voltage systems up to 690 V. It measures true RMS values, harmonic content up to the 63rd harmonic, and can handle AC sine signals at 50/60Hz. Designed for reliable operation in industrial environments, it features a compact design, LCD display, CE compliance, and supports various current and voltage input ranges for versatile applications.
Phoenix Contact 2908286 Energy Meter Specifications:
- Dimensions: Width 96 mm, Height 96 mm, Depth 58 mm
- Ambient temperature (operation): -10°C to 55°C
- Ambient temperature (storage/transport): -40°C to 70°C
- Maximum altitude: < 2000 m
- Degree of protection: IP52
- Input voltage range: 35 VAC to 690 V AC (Phase/Phase), 20 VAC to 400 V AC (Phase/neutral), 60 VAC to 2,000,000 V AC (primary)
- Surge voltage capacity: 760 V AC
- Input current: 4000 A, response threshold 5A, precision <1%
- Reactive power class: 2 (IEC 62053-23)
- Input signals: Voltage OVDC...30V DC, current 2mA...15mA
- Output: Digital output IEC/EN 61131-2 type 3, current <100 mA
- Display: LCD, two-color backlit
- Supply voltage: 100 V AC to 400 V AC, power consumption <4W
- Conformance: CE, China RoHS, UL, EAC
- Connection: Screw connection, conductor cross section 0.2mm² to 6mm², torque 0.5-0.6 Nm
- Certifications: CE, UL, EAC, Ex approvals
Buy the Phoenix Contact Series EMpro Energy Meter: 2908286
Purchase the Phoenix Contact 2908286 energy meter online today to enhance your electrical system monitoring with high accuracy, reliable data acquisition, and versatile measurement capabilities. Designed for low-voltage installations up to 690 V, this device offers true RMS measurement, harmonic analysis, and easy integration via Modbus/TCP. Its compact design, LCD display, and CE certification make it ideal for industrial applications. Secure your order now and enjoy efficient, precise energy monitoring for your electrical infrastructure.
Get Phoenix Contact 2908286 today—built for precision and robust energy measurement in industrial systems.
