Phoenix Contact FMC1512ST381 PCB connector
The FMC 1.5/12-ST-3.81 is a green printed-circuit board connector designed for reliable quick connection in industrial environments. Featuring 12 positions, a pitch of 3.81 mm, and a push-in spring connection, it provides efficient, time-saving installation without tools. The contact surface is tin-plated, supporting maximum load currents of 8A at rated voltages up to 160V. Its compact dimensions and robust PA insulation make it suitable for front-device integration, ensuring stable, long-term connectivity for automation and control applications.
Phoenix Contact FMC1512ST381 PCB connector Specifications:
- Number of positions: 12
- Pitch: 3.81 mm
- Rated current: 8 A
- Rated voltage: 160 V
- Connection method: Push-in spring connection
- Contact surface: Tin-plated
- Insulating material: PA
- Flammability rating: UL 94 vo
- Conductor cross section: 0.2-1.5 mm² / AWG 24-16
- Dimensions: Length 21.9 mm, width 46.16 mm, height 7.75 mm, a 41.91 mm
- Mounting: Front device integration, wave or press-in soldering, TBD
- Standard compliance: EN-VDE, UL 94
- Environmental: RoHS compliant, unlimited environmental use period
Buy the Phoenix Contact FMC 1.5/12-ST-3.81 – Reliable PCB Connector for Industrial Applications
Enhance your automation setup with the Phoenix Contact FMC 1.5/12-ST-3.81 PCB connector, offering quick push-in spring connection, robust tin contacts, and reliable performance at 8A and 160V. Its compact design fits easily on control panels and front devices. Suitable for PCB wiring in industrial environments, this connector ensures long-lasting, stable connections. Easy to install with no tools required, it supports wire sizes from 0.2 to 1.5 mm², making it a dependable choice for automation, control systems, and manufacturing process applications.
Order your Phoenix Contact FMC 1.5/12-ST-3.81 today and benefit from its efficient push-in connection, long-term stability, and quick installation for your automation projects.
