Phoenix Contact CDDC152PV35 PCB Connector
The PCB direct plug CDDC 1.5/2-PV-3.5 is a reliable connecto featuring SKEDD direct plug-in technology, designed for high-density PCB wiring with 2 positions and a 3.5 mm pitch. It supports a nominal current of 8 A and rated voltage of 160 V, suitable for industrial automation and electrical systems. The connection is made via crimp contacts with a 26-16 AWG range, and the housing is green made of flame-retardant PA with a self-locking flange. Its vibration resistance, flexible positioning, and compatibility with various surface finishes make it ideal for diverse industrial applications.
Phoenix Contact CDDC152PV35 PCB Connector Specifications:
- Number of positions: 2
- Pitch: 3.5 mm
- Nominal current: 8 A
- Rated voltage: 160 V (IEC/UL)
- Connection method: Crimp connection
- Conductor cross section: 0.14 mm² ... 1.5 mm² / AWG 26 ... 16
- Housing material: PA (Polyamide)
- Housing color: Green (6021)
- Flammability rating: UL 94 vo
- CTI: 600
- Temperature limits (assembly): -5°C ... 100°C
- Temperature limits (operation): -55°C ... 105°C
- Dimensions: Length varies, typical width and height depend on model, pin spacing: 3.5 mm
- Locking: Self-locking flange
- Ingress protection: IP20
- Compliance and approvals: UL Recognized, VDE, IEC CB Scheme
- Compliance standards: IEC 60664-1, IEC 61984, IEC 60512
Buy the Phoenix Contact CDDC152PV35 – Reliable PCB Connectors for Industrial Applications
Purchase the Phoenix Contact PCB Connector CDDC 1.5/2-PV-3.5 online today to ensure a secure, vibration-resistant, and easy-to-install connection solution for industrial automation. This connector offers a high current capacity of 8 A and rated voltage of 160 V, utilizing SKEDD direct plug-in technology, simplifying mounting with vibration resistance. Its compact design, crimp connection, and compatibility with various PCB surface finishes make it ideal for manufacturing, automation, and electrical systems. Order now and streamline your assembly process with high-quality components designed for durability and efficiency.
Buy Phoenix Contact CDDC152PV35 now and experience reliable, vibration-resistant PCB connection technology for your industrial projects.
Frequently Asked Questions
Where can I buy Phoenix Contact CDDC152PV35?
You can click on the BUY or RFQ button to purchase CDDC152PV35 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part CDDC152PV35?
You can download the CDDC152PV35 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of CDDC152PV35?
Phoenix Contact
