Phoenix Contact CDDC252PV50 PCB connector
The CDDC 2,5/2-PV-5,0 connector is a versatile PCB direct plug-in solution utilizing SKEDD technology, supporting a nominal current of 12 A and rated voltage of 320 V. It features a 5 mm pitch, 2 positions, and is suitable for high-density PCB applications thanks to its double-row contact arrangement. Made of flame-retardant PA with a green housing, it offers vibration resistance, easy hand-insertion, and compatibility with various surface finishes. Certified by UL and VDE, it ensures reliable power connections in industrial settings.
Phoenix Contact CDDC252PV50 PCB connector Specifications:
- Connection method: Crimp connection
- Mounting type: SKEDD direct plug-in technology
- Pin layout: Linear pinning
- Number of positions: 2
- Pitch: 5 mm
- Rated current: 12 A
- Rated voltage: 320 V
- Conductor cross section: 0.14 mm² to 2.5 mm²
- Conductor AWG/Kemil: 6-14
- Housing color: Green (6021)
- Housing material: PA
- Flammability rating: UL 94 VO
- CTI: 600
- Insulation resistance: >1.6 TO
- Impact and vibration resistance certified per IEC standards
- Ambient temperature (operation): -55°C to 105°C
- Minimum clearance: 3 mm
- Minimum creepage distance: 3.2 mm
- Approvals: UL, VDE Recognized
- Dimensions: Length approx. 13 mm, width and height as per technical datasheet
- Number of connection levels: 2
- Locking: Self-locking flange
Buy the Phoenix Contact CDDC 2,5/ 2-PV-5,0 U+2013 Reliable PCB Connectors for Industrial Applications
Purchase the Phoenix Contact CDDC 2,5/ 2-PV-5,0 connector online today and benefit from quick, easy insertion thanks to SKEDD technology. With a compact design, 12A current capacity, and rated voltage of 320V, this high-quality green housing connector provides vibration resistance and is suitable for dense PCB layouts. It supports flexible conductor cross sections from 0.14 mm² to 2.5 mm², ensuring reliable power distribution. Certified for safety, it guarantees consistent performance in industrial environments, making it a dependable choice for your electrical assembly needs.
Order your Phoenix Contact Series CDDC 2,5/ 2-PV-5,0 direct connector today and ensure a reliable, vibration-resistant power connection in your industrial projects.
Frequently Asked Questions
Where can I buy Phoenix Contact CDDC252PV50?
You can click on the BUY or RFQ button to purchase CDDC252PV50 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part CDDC252PV50?
You can download the CDDC252PV50 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of CDDC252PV50?
Phoenix Contact
